CTI On-Board IS 8 - SERVICE

Consumable parts vary with model type.

Brooks CTI-Cryogenics On-Board IS 8 - Scope of Work

One year warranty repair service.

PTB Sales will perform the following:

1. Incoming Inspection

• Attach work order to cryopump
• Picture taken of cryopump's mechanical configuration
• S/W version recorded on work order

2. Complete teardown and disassembly of the pump

3. All parts are inspected and cleaned

• Aqueous high pressure parts washer

4. Parts are dimensionally evaluated

5. Cryopump Rebuild

• Vacuum Rebuild
  • Replace 15K array
  • Replace 80K condensing array
  • Replace radiation shield
  • Replace 1st and 2nd stage temperature sensors and wires
  • Replace O-rings in rough valve and purge valve
  • Replace all hardware
  • Verify / replace heater operation
  • Verify / replace vacuum vessel
• Refrigerator Rebuild
  • Replace O-rings, seals and bushings in the cross head assembly
  • Replace the rocker valve springs, lock nuts and gland
  • Replace supply and return aeroquip connectors
  • Replace dowel pin for the displacer cap nut
  • Inspect / replace scotch yoke
  • Replace valves and valve stems
  • Inspect / replace crankshaft and drive assembly
  • Inspect / replace rocker arms / assembly
• Drive Motor Rebuild
  • Replace bearings
  • Replace O-rings
  • Inspect / replace motor shaft

6. Module Rebuild

• Customer data uploaded into database
• Battery replaced
• PCB's inspected
• Inspect / replace power components > 5 years old
• Inspect / replace I/O connectors (RS-232, USB, HDDB15, power)

7. Sub Assembly Test

• Module test
• Motor test
• Refrigeration load test
• Set / test timing of exhaust and inlet valves
• Verify diode characterization

8. Final Test

• Vacuum sided leaked checked to 1 x 1E^-9 sccm
• Helium circuit leaked checked to 5 x 10E^-8 sccm
• Perform two full regenerations
  • Time to reach <17K verified
  • Time to reach <= 12K (bottom out temperature) verified
  • Run pump in temperature control at 100K for 30 minutes
• Runtime hours reset to zero
• Fast and full regeneration history cleared

9. Final Quality Control Check List

• Picture taken of cryopump’s as shipped configuration
• Final test report attached to cryopump
• Protective covers installed on all vacuum flanges
• Protective covers installed on power and I/O connectors
• Package with accordance with DOT Standards
