EBARA ESA70W - NEW
Call for Price
In stock
SKU
NEW_ESA70W
| Weight | 836 lbs |
|---|---|
| Pumping Speed | 274 cfm |
| Ultimate Pressure | 4 x 10-3 mbar |
EBARA ESA70W Light Gas Dry Vacuum Pump - NEW
The ESA Series consists of a two-stage main pump design engineered for application in harsh duty processes. The main pump is packaged with a lobe style booster pump for increased pumping speed.
The ESA Series covers a wide pumping speed range from 88 to 1,765 cfm. ESA pumps are designed and manufactured to be the lowest cost of ownership pumps on the market today. The main pump is constructed of NiResist, a solid cast material known for its superior corrosion resistance.
- Low cost of ownership [power, N2, water, footprint, volume, weight]
- Variable pumping speed to match application requirements
- High performance brushless DC motor on the booster pump
- State-of-the-art control and monitoring devices
- Idle mode can be employed for increased utility savings
- SEMI S2 assessed, NRTL Listed, CE Marked
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Pumping speed 50/60 Hz | 274 / 296 cfm 7,000 / 8,400 l/min 420 / 504 m3/hr |
| Ultimate pressure 50/60 Hz | 3 / 2 mTorr 0.4 / 0.27 Pa 0.004 / .0027 mBar |
| Gas inlet connection | NW 50 |
| Gas outlet connection | NW 40 |
| Power at ultimate pressure | kW |
| Maximum power | kW |
| Cooling water requirements, min. flow rate | 3.5 l/min |
| Bearing and dilution N2, bearing seals | 15 l/min |
| Cabinet dimensions, L x W x H | 39.3 x 15.7 x 31.5 in 997 x 400 x 800 mm |
| Weight | 836 lbs 380 kg |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
