Edwards D-LAB - NEW

Name: Edwards D-LAB - NEW
Brand: Edwards
SKU: NEW_D-LAB

Be the first to review this product

Call for Price

In stock

SKU

NEW_D-LAB

Request For Quote

Weight	13 lbs
Pumping Speed	0.6 m³/h
Ultimate Pressure	1 x 10² mbar

Description

Edwards D-LAB Diaphragm Vacuum Pump - NEW

The Edwards range of D-Lab diaphragm pumps offer clean pumping in a lightweight and compact design making them ideal for many laboratory applications. Pumps can operate independently and require minimal maintenance. The D-Lab pumps are single and double head pumps with pumping speeds up to 2 m3/hr.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Specification

Pumping speed (air)
10-100, 10-8	0.6 m³h^-1, 10 lmin^-1
20-100, 20-8	1.2 m³h^-1, 20 lmin^-1
34-100, 34-8	2 m³h^-1, 34 lmin^-1
Ultimate vacuum
10-100, 20-100, 34-100	100 mbar 50Hz, 75 mbar 60Hz
10-8, 20-8, 34-8	8 mbar 50Hz, 6 mbar 60Hz
Inlet and outlet connection	Riffled nozzle, suitable for 9 mm i.d. hose
Maximum inlet pressure	1 bar
Motor power and current
10-100, 110V 60Hz	110 W 1.3 A
10-100, 220-240V 50Hz	100 W 0.6 A
20-100, 110V 60Hz	145 W 1.9 A
20-100, 220-240V 50Hz	130 W 0.9 A
34-100, 110V 60Hz	220 W 3.2 A
34-100, 220-240V 50Hz	180 W 1.4 A
10-8, 100V 60Hz	110 W 1.3 A
10-8, 220-240V 50Hz	90 W 0.6 A
20-8, 110V 60Hz	130 W 1.2 A
20-8, 220-240V 50Hz	120 W 0.9 A
34-8, 110V 60Hz	250 W 3.2 A
34-8, 220-240V 50Hz	200 W 1.5 A
Enclosure rating	IP44
Operating temperature	5 - 40 ºC
Weight
10-100	5.8kg / 12.8lbs
20-100	7.1kg / 15.6lbs
34-100	10.3kg / 22.7lbs
10-8	6.9kg / 15.2lbs
20-8	9.3kg / 20.5lbs
34-8	12.6kg / 27.7lbs

Specifications

RFQ/Configuration

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Edwards D-LAB Diaphragm Vacuum Pump - NEW

A48015941 10-100, 110V, 60Hz, 1-ph
A48015960 10-100, 220 –240, 50Hz, 1-ph
A48016960 10-8, 220 -240~ 50Hz, 1-ph
A48017941 20-100, 110V 60Hz, 1-ph
A48017960 20-100, 220- 240~ 50Hz, 1-ph
A48018960 20-8, 220-240V 50Hz, 1-ph
A48021941 34-100, 110~ 60Hz, 1-ph
A48021960 34-100, 220- 240~ 50Hz, 1-ph
A48022941 34-8, 110V 60Hz, 1-ph
A48016941 10-8, 110 V 1-phase 60 Hz
A48018941 20-8, 110 V 1-phase 60 Hz
A48022960 34-8, 220-240 V 1-phase 50 Hz
