Edwards GV260 DRYSTAR - REBUILT
Call for Price
| Weight | 1781 lbs |
|---|---|
| Pumping Speed | 240 m3/h |
| Ultimate Pressure | 4 x 10-1 mbar |
Edwards GV260 DRYSTAR Industrial Dry Vacuum Pump - REBUILT
The DRYSTAR® GV80 – 600M range is based on the well proven Edwards reverse claw mechanism reaching a peak speed of 560 m3h-1 / 330 ft3min-1. The reverse claw mechanism results in short gas paths within the operating mechanism, providing the ability to handle large amounts of dust and water vapor, when compared to oil sealed pumps, without deterioration of performance. The GV range is able to handle large amounts of dust and water vapor with little or no effect on performance. Advantages to this include:
- Low cost of ownership in harsh conditions
- High reliability – dry mechanism proven in 100,000 installations
- Oil free mechanism – reduced maintenance
- Higher dust and water vapor tolerance
- Accessories to optimize pump performance to process variables
- Fast pump down with Edwards hydrokinetic drive booster pumps.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| GV260 | 50 Hz | 60 Hz |
|---|---|---|
| Displacement | 336 m3h-1 | 405 m3h-1 |
| Pumping speed | 240 m3h-1 | 320 m3h-1 |
| Ultimate pressure | < 0.065 mbar | < 0.04 mbar |
| Continuous power | 11 kW | 20 hp |
| Cooling-water flow at 20°C | 5.0 l/min | |
| Noise level | < 76 dB(A) | < 78 dB(A) |
| Weight | 767 kg / 1,691 lbs | 785 kg / 1,731 lbs |
| Electrical supply | 380 - 415 V | 230 / 460 V |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards GV DRYSTAR Series - REBUILT | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards GV260 DRYSTAR Industrial Dry Vacuum Pump - REBUILT A70571900 / A705-71-900 GV260 380 - 415 V 50 Hz A70571908 / A705-71-908 GV260 230 / 460 V 60 Hz
