Edwards iH600 - NEW
Call for Price
| Weight | 915 lbs |
|---|---|
| Motor Power | 8.2 hp |
| Pumping Speed | 600 m3h-1 |
| Ultimate Pressure | 5.3x 10-4 torr |
Edwards iH600 Semiconductor Dry Vacuum Pump - NEW
Edwards advanced semiconductor vacuum pumps have been field-proven to perform to the highest operating standards. Reliability and high performance are achieved by extending service life, improving uptime and increasing productivity, while minimizing footprint and cost of ownership.
The iH Series offers high reliability for difficult processes, such as PECVD and LPCVD, where particulate, condensable and corrosive by-products are present.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
|
Peak speed |
600 m3h-1 353 cfm 10,000 lmin-1 |
| Ultimate vacuum | 7 x 10-4 mbar 5.3 x 10-4 Torr 0.07 Pa |
| Typical shaft seal nitrogen flow | 4 slm |
| Inlet connection | ISO100 |
| Outlet connection | NW40 |
| Typical cooling water flow at 15 psi pressure drop | 240 lh-1 4 lmin-1 |
| Weight | 415 kg |
| Power input at ultimate | 3.4 kW |
| Rated motor power | 6.1 kW |
| Oil capacity | 1.43 l |
All figures are typical without gas ballast.
Specifications
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards iH600 Semiconductor Dry Vacuum Pump - NEW A59020908 / A590-20-908 iH600 MK5 460V 60Hz three-phase A59020945 / A590-20-945 iH600 MK5 200/208V 50/60Hz 3-phase A59020946 / A590-20-946 iH600 MK5 380/415V 50/60Hz 3-phase A59020957 / A590-20-957 iH600 MK5 230V 60Hz 3-phase
