Edwards nES200 - NEW
Weight
313 lbs
Motor Power
6 hp
Pumping Speed
170 m3 /h
Ultimate Pressure
8 x 10-2 mbar
Edwards nES200 Single Stage Rotary Vane Vacuum Pump - NEW
The Edwards nES single stage series represents the next advancement in oil sealed rotary vane vacuum pumps for use in a wide of range industries and applications. Offering high reliability, low life cycle cost and proven performance, the nES series provides an ideal solution to suit a broad range of requirements.
Maximum Displacement
50 Hz
180 m3 h-1 /106 cfm
60 Hz
230 m3 h-1 /130 cfm
Pumping Speed
50 Hz
170 m3 h-1 /100 cfm
60 Hz
200 m3 h-1 /118 cfm
Ultimate vacuum (total pressure) no gas ballast
0.08 mbar /0.06 Torr
Ultimate vacuum (total pressure) with gas ballast
0.7 mbar /0.5 Torr
Inlet Connection
63 ISO-F / G2
Outlet Connection
63 ISO-F / G2
Max permitted outlet pressure
1.15 bar gauge
Max water vapour pumping rate
50Hz
3.4 kgh-1 /3.6 lbh-1
60Hz
5.4 kgh-1 /5.7 lbh-1
Weight
142 kg /313 lb
Motor Protection rating
IP55
Motor Power
50Hz
4.5 kW /6.0 hp
60Hz
5.5 kW /7.5 hp
Noise level
50Hz
69 dB(A)
60Hz
73 dB(A)
Oil refill capacity
5-9 Litre
Recommended oil
Ultragrade 40
Type
Label
Description
Download
Edwards nES Series - New
Instruction Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
