Edwards nES65 - NEW
Call for Price
In stock
SKU
NEW_nES65
| Weight | 190 lbs |
|---|---|
| Motor Power | 3 hp |
| Pumping Speed | 54.0 m3/h |
| Ultimate Pressure | 5 x 10-1 mbar |
Edwards nES65 Single Stage Rotary Vane Vacuum Pump - NEW
The Edwards nES single stage series represents the next advancement in oil sealed rotary vane vacuum pumps for use in a wide of range industries and applications. Offering high reliability, low life cycle cost and proven performance, the nES series provides an ideal solution to suit a broad range of requirements.
| Maximum Displacement | |
| 50 Hz | 59.0 m3h-1 /34.8 cfm |
| 60 Hz | 71 m3h-1 /41.8 cfm |
| Pumping Speed | |
| 50 Hz | 54 m3h-1 /31.8 cfm |
| 60 Hz | 64 m3h-1 /37.7 cfm |
| Ultimate vacuum (total pressure) no gas ballast | 0.5 mbar /0.4 Torr |
| Ultimate vacuum (total pressure) with gas ballast | 1.5 mbar /1.1 Torr |
| Inlet Connection | 40 ISO-F / G1 ¼ |
| Outlet Connection | 40 ISO-F / G1 ¼ |
| Max permitted outlet pressure | 1.15 bar gauge |
| Max water vapour pumping rate | |
| 50Hz | 1.0 kgh-1 /1.1 lbh-1 |
| 60Hz | 1.25 kgh-1 /1.32 lbh-1 |
| Weight | 86 kg /190 lbs |
| Motor Protection rating | IP55 |
| Motor Power | |
| 50Hz | 1.5 kW /2.0 hp |
| 60Hz | 1.8 kW /3.0 hp |
| Noise level | |
| 50Hz | 60 dB(A) |
| 60Hz | 64 dB(A) |
| Oil refill capacity | 4 Litre |
| Recommended oil | Ultragrade 70 |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards nES Series - New | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards nES65 Single Stage Rotary Vane Vacuum Pump - NEW
