Edwards RV12 PFPE - NEW
Call for Price
| Weight | 63.8 lbs |
|---|---|
| Motor Power | 0.74 hp |
| Pumping Speed | 12 m3/h |
| Ultimate Pressure | 2 x 10-3 mbar |
Edwards RV12 PFPE Two Stage Rotary Vane Vacuum Pump - NEW
Edwards RV pumps have become the industry standard for scientific primary pumping applications. RV pumps are uniquely capable of delivering high or low throughputs with high ultimate vacuum. This, combined with ultra-low noise levels, makes them ideal for a wide range of applications including GCMS and other small bench top type applications. All pumps are approved to UL and CSA standards by an external test house. Edwards has a global network, providing world-wide support for product applications and service.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Displacement (swept volume) | |
| 50 Hz | 14.2 m3h-1 / 8.4 ft3min-1 |
| 60 Hz | 17 m3h-1 / 10 ft3min-1 |
| Speed (Pneurop 6602) | |
| 50 Hz | 12 m3h-1 / 7.1 ft3min-1 |
| 60 Hz | 14.2 m3h-1 / 8.4 ft3min-1 |
| Ultimate pressure | 2.0 x 10-3 mbar / 1.5 x 10-3 Torr |
| Ultimate pressure GB I | 3.0 x 10-2 mbar / 2.3 x 10-2 Torr |
| Ultimate pressure GB II | 6.0 x 10-1 mbar / 4.6 x 10-2 Torr |
| Ultimate pressure w/ Fomblin® | 2.0 x 10-2 mbar / 1.5 x 10-2 Torr |
| Maximum inlet pressure for water vapour | 32 mbar / 24 Torr |
| Maximum water vapour pumping rate - GB I | 60 gh-1 |
| Maximum water vapour pumping rate - GB II | 220 gh-1 |
| Max allowed outlet pressure | 0.2 bar gauge / 2.8 psig |
| Max allowed inlet and gas ballast pressure | 0.5 bar gauge / 7 psig |
| Motor power 50/60Hz | 450 / 550W |
| Power connector 1-phase | IEC EN60320 C13 |
| Nominal rotation speed 50/60Hz | 1,500 / 1,800 rpm |
| Weight (w/out oil) | 29 kg / 63.8 lbs |
| Oil capacity min/max | 0.65 / 1 litre |
| Inlet flange | NW25 |
| Exhaust flange | NW25 |
| Noise level | 48 dB(A) @ 50 Hz |
| Recommended oil | Ultragrade 19 |
| Operating temperature range | 12 – 40°C |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards RV Series - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards MODEL RV12 PFPE Two Stage Rotary Vane Vacuum Pump - NEW
