Edwards RV8 - NEW

Starting at $3,870
In stock
Only %1 left
SKU
NEW_RV8
Weight 61.6 lbs
Motor Power 0.60 hp
Pumping Speed 8.5 m3/h
Ultimate Pressure 2 x 10-3 mbar

Edwards RV8 Two Stage Rotary Vane Vacuum Pump - NEW

Edwards RV pumps have become the industry standard for scientific primary pumping applications. RV pumps are uniquely capable of delivering high or low throughputs with high ultimate vacuum. This, combined with ultra-low noise levels, makes them ideal for a wide range of applications including GCMS and other small bench top type applications. All pumps are approved to UL and CSA standards by an external test house. Edwards has a global network, providing world-wide support for product applications and service.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Displacement (swept volume)
50 Hz 9.7 m3h-1 / 5.7 ft3min-1
60 Hz 11.7 m3h-1 / 6.9 ft3min-1
Speed (Pneurop 6602)
50 Hz 8.5 m3h-1 / 5.0 ft3min-1
60 Hz 10 m3h-1 / 5.9 ft3min-1
Ultimate pressure 2.0 x 10-3 mbar / 1.5 x 10-3 Torr
Ultimate pressure GB I 3.0 x 10-2 mbar / 2.3 x 10-2 Torr
Ultimate pressure GB II 6.0 x 10-1 mbar / 4.6 x 10-2 Torr
Ultimate pressure w/ Fomblin® 2.0 x 10-2 mbar / 1.5 x 10-2 Torr
Maximum inlet pressure for water vapour 38 mbar / 28.5 Torr
Maximum water vapour pumping rate - GB I 60 gh-1
Maximum water vapour pumping rate - GB II 220 gh-1
Max allowed outlet pressure 0.2 bar gauge / 2.8 psig
Max allowed inlet and gas ballast pressure 0.5 bar gauge / 7 psig
Motor power 50/60Hz 450 / 550W
Power connector 1-phase IEC EN60320 C13
Nominal rotation speed 50/60Hz 1,500 / 1,800 rpm
Weight (w/out oil) 28 kg / 61.6 lbs
Oil capacity min/max 0.45/0.75 litre
Inlet flange NW25
Exhaust flange NW25
Noise level 48 dB(A) @ 50 Hz
Recommended oil Ultragrade 19
Operating temperature range 12 – 40°C

Specifications

Digital Manuals
Type Label Description Download
Edwards RV Series - REBUILT Instruction manual Download
Edwards RV Series - NEW Instruction Manual Download
RFQ/Configuration

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Edwards MODEL RV8 Hydrocarbon Two Stage Rotary Vane Vacuum Pump - NEW

CODE No. A654-01-903 / A65401903  RV8  115/230V, single-phase, 50/60Hz, Factory set to 230V for Europe
CODE No. A654-01-904 / A65401904  RV8  100/200V, 1-phase, 50/60Hz, Factory set to 200V for Japan
CODE No. A654-01-906 / A65401906  RV8  115/230V, 1-phase, 50/60Hz, Factory set to 115V for USA
         A654-01-905 / A65401905  RV8  200-220/380-415V, three-phase, 50Hz and 200-230/460V, 3-phase, 60Hz, Factory set to 380/460V
         A654-01-903 / A65401903  RV8  115/240V 1-phase 50/60Hz
         A654-01-903 / A65401903  RV8  115/240V 1-phase 50/60Hz
         A654-01-906 / A65401906  RV8  115V 1-phase 50/60Hz USA ONLY
         A654-09-903 / A65409903  RV8 PFPE  115/230V, 1-phase, 50/60Hz, Factory set to 230V for Europe
         A654-09-906 / A65409906  RV8 PFPE  115/230V, 1-phase, 50/60Hz, Factory set to 115V for Europe
         A654-09-904 / A65409904  RV8 PFPE  100/200V, 1-phase, 50/60Hz, Factory set to 200V for Japan
         A654-09-905 / A65409905  RV8 PFPE  200-220/380-415V, 3-phase, 50Hz, and 200-230/460V, 3-phase, 60Hz, Factory set to 380/460V

Atlas Copco GVD 8  1-phase 110-120V 50/60Hz
Atlas Copco GVD 8  1-phase 220-240V 50/60Hz
Atlas Copco GVD 8  3-phase 208-230/460V 50/60Hz
