Edwards Stokes 212J Microvac - NEW
Weight
950 lbs
Motor Power
7.5 hp
Pumping Speed
234 m3 /h
Ultimate Pressure
< 3.3 x 10-2 mbar
Edwards Stokes 212J Microvac Rotary Piston Vacuum Pump - NEW
The Edwards Microvac rotary piston pumps set the standard for performance and reliability as the industries most efficient, space saving design. The design has been improved, upgraded and fine tuned to deliver even better dependability and productivity combined with minimal maintanance and process downtime.
Questions? send an email to our sales team!
Displacement (swept volume)
255 m3 h-1 / 150 ft3 min-1
Pumping speed
234 m3 h-1 / 138 ft3 min-1
Ultimate vacuum (total pressure)
w/out gas ballast
< 3.3 x 10-2 mbar / < 2.5 x 10-2 Torr
w/ gas ballast
< 2.6 x 10-2 mbar / < 2 x 10-2 Torr
50Hz motor size (TEFC)
5.5 kW IEC (CE variant)
60Hz motor size (TEFC)
7.5 hp TEFC
Motor speed
1,800 rpm
Inlet connection
3 inch ASA/ANSI flange
Exhaust connection
2 inch ASA/ANSI flange or 2 inch NPT
Water inlet/outlet connection
1/2 inch NPT
Recommended cooling flow @ 85°C / 30°F
5.7 lmin-1 / 1.5 gal min-1
Water vapour pumping rate
5 kg h-1 / 11 lb h-1
Oil capacity
15 litre / 4 gal
Recommended oil
V lube F
Noise
< 77 dB(A)
Weight
431 kg / 950 lbs
Specs
Type
Label
Description
Download
Edwards Stokes Microvac Series - REBUILT
Instruction Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards Stokes 212J Microvac Rotary Piston Vacuum Pump - NEW
900212014 212J 230/460V three-phase 60Hz (230/460V coil)
900212014503 212J 400V 3-phase 50Hz IEC motor 380V coil w/ water miser (CE compliant)
900212014501 212J 400V 3-phase 50Hz IEC motor 380V coil (CE compliant)
900212014504 212J 400V 3-phase 50Hz IEC motor 415V coil w/ water miser (CE compliant)
900212014502 212J 400V 3-phase 50Hz IEC motor 415V coil (CE compliant)
Atlas Copco GLS250 3-phase 230/460V 60Hz
