Edwards Stokes 310 - REBUILT
Call for Price
In stock
SKU
REBUILT_310
| Weight | 240 lbs |
|---|---|
| Motor Power | 5 hp |
Edwards Stokes 310 Roots Vacuum Blower - REBUILT
The Stokes 3" Series mechanical booster pumps provide high throughput pumps for industrial and arduous chemical applications. Utilizing reliable, rugged designs, these pumps offer a low cost, space saving pumping system.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Stokes 310 | Direct Drive | V-Belt Drive |
|---|---|---|
| Displacement | 400 cfm / 680 m3hr | |
| Motor speed | 60 Hz: 3,600 rpm | |
| Inlet / outlet flanges | 4" ASA | |
| Oil capacity | 1.75 pints / 0.83 liters | |
| Max. pressure differential | 380 Torr | |
| Max. temperature rise | 275°F / 135°C | |
| Max. discharge temperature | 375°F / 191°C | |
| Drive hp | 5 hp Max | |
| Weight | 240 lb / 109 kg | 190 lb / 86 kg |
| Type | Label | Description | Download |
|---|---|---|---|
|
BOC Edwards Stokes 306 & 310 - REBUILT | User's Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards Stokes 310 Roots Vacuum Blower - REBUILT 900-310-1 310-1 / 310-001 Vertical flow V-belt drive 900-310-2 310-2 / 310-002 Horizontal flow V-belt drive foot mounting 900-310-401 310-401 310-41 Vertical flow direct drive 900-310-402 310-402 310-42 Horizontal flow direct drive foot mounting
