Edwards Stokes 212H-11 Microvac - REBUILT
Weight |
1,075 lbs |
Motor Power |
10 hp |
Pumping Speed |
150 cfm |
Ultimate Pressure |
1.3 x 10-2 mbar |
Edwards Stokes 212H-11 Microvac Rotary Piston Vacuum Pump - REBUILT
As part of the Atlas Copco group, Stokes Vacuum continues to innovate oil-lubricated rotary piston pumps.
Features & Benefits
- Low ultimate blank off - pressures down to 10 microns and lower.
- High efficiency pump - 80% or better even down to 0.1 mm range.
- Quiet operation - valve design virtually eliminates valve maintenance and noise.
- Automatic lubrication - system provides proper flow of oil to bearings and sealing surfaces, prevents back flow into system.
- Controlled balancing - reduces vibration to practical minimum.
- Gas ballast - standard on all models.
- Our Stokes vacuum piston pumps come rebuilt with a one year warranty.
- We also offer blower packages and repair service.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
Ultimate vacuum |
10 microns Hg. or less |
Displacement |
150 cfm |
Pump speed |
500 rpm |
Motor |
10 hp |
Std. electrical specs |
3-phase 60 Hz 230/460V |
Motor speed |
1,800 rpm |
Pipe connections |
Suction |
3" flanged |
Discharge |
2" screwed |
Water inlet |
1/2" NPT |
Water outlet |
1/2" NPT |
Oil capacity |
4 gals |
Net weight |
950 lbs |
Shipping weight |
appx. 1,075 lbs |
Height |
43.5" |
Cooling |
Water cooled |
Specifications
Type |
Label |
Description |
Download |
|
Stokes Microvac Series - REBUILT |
Operating Instructions |
Download
|
