Edwards Stokes 412J Microvac - NEW
Starting at
$27,572
In stock
Only %1 left
SKU
NEW_412J
| Weight | 1,750 lbs |
|---|---|
| Motor Power | 10 hp |
| Pumping Speed | 442 m3/h |
| Ultimate Pressure | < 3.3 x 10-2 mbar |
Edwards Stokes 412J Microvac Rotary Piston Vacuum Pump - NEW
The Edwards Microvac rotary piston pumps set the standard for performance and reliability as the industries most efficient, space saving design. The design has been improved, upgraded and fine tuned to deliver even better dependability and productivity combined with minimal maintanance and process downtime.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Displacement (swept volume) (AVS) | 510 m3h-1 / 300 ft3min-1 |
| Pumping speed | 442 m3h-1 / 260 ft3min-1 |
| Ultimate vacuum (total pressure) | |
| w/out gas ballast | < 3.3 x 10-2 mbar / < 2.5 x 10-2 Torr |
| w/ gas ballast | < 2.6 x 10-1 mbar / < 2 x 10-1 Torr |
| 50Hz motor size (TEFC) | 11 kW IEC (CE variant) |
| 60Hz motor size (TEFC) | 10 hp TEFC |
| Motor speed | 1,800 rpm |
| Inlet connection | 4 inch ASA/ANSI flange |
| Exhaust connection | 3 inch ASA/ANSI flange or 3 inch NPT |
| Water inlet/outlet connection | 1/2 inch NPT |
| Recommended cooling flow @ 85°C / 30°F | 7.6 lmin-1 / 1.5 gal min-1 |
| Water vapour pumping rate | 10.45 kg h-1 / 23 lb h-1 |
| Oil capacity | 46 litre / 12 gal |
| Recommended oil | V lube F |
| Noise | < 83 dB(A) |
| Weight | 794 kg / 1,750 lbs |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards Stokes Microvac Series - REBUILT | Instruction Manual | Download |
|
Edwards Microvac Series - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards Stokes 412J Microvac Rotary Piston Vacuum Pump - NEW 900412014 412J 230/460V three-phase 60Hz (230/460V coil) 900412014503 412J 400V 3-phase 50Hz IEC motor 380V coil w/ water miser (CE compliant) 900412014501 412J 400V 3-phase 50Hz IEC motor 380V coil (CE compliant) 900412014504 412J 400V 3-phase 50Hz IEC motor 415V coil w/ water miser (CE compliant) 900412014502 412J 400V 3-phase 50Hz IEC motor 415V coil (CE compliant) Atlas Copco GLS500 3-phase 230/460V 60Hz
