Edwards 412-14 Microvac - REBUILT
Weight
1,975 lbs
Motor Power
10 hp
Pumping Speed
442 cfm
Ultimate Pressure
3.3 x 10-2 mbar
Edwards Stokes 412J Microvac Rotary Piston Vacuum Pump - REBUILT
The Edwards Microvac rotary piston pumps set the standard for performance and reliability as the industries most efficient, space saving design. The design has been improved, upgraded and fine tuned to deliver even better dependability and productivity combined with minimal maintanance and process downtime.
Questions? send an email to our sales team!
Displacement (swept volume) (AVS)
510 m3 h-1 / 300 ft3 min-1
Pumping speed
442 m3 h-1 / 260 ft3 min-1
Ultimate vacuum (total pressure)
w/out gas ballast
< 3.3 x 10-2 mbar / < 2.5 x 10-2 Torr
w/ gas ballast
< 2.6 x 10-1 mbar / < 2 x 10-1 Torr
50Hz motor size (TEFC)
11 kW IEC (CE variant)
60Hz motor size (TEFC)
10 hp TEFC
Motor speed
1,800 rpm
Inlet connection
4 inch ASA/ANSI flange
Exhaust connection
3 inch ASA/ANSI flange or 3 inch NPT
Water inlet/outlet connection
1/2 inch NPT
Recommended cooling flow @ 85°C / 30°F
7.6 lmin-1 / 1.5 gal min-1
Water vapour pumping rate
10.45 kg h-1 / 23 lb h-1
Oil capacity
46 litre / 12 gal
Recommended oil
V lube F
Noise
< 83 dB(A)
Shipping Weight
1,975 lbs
Specifications
Type
Label
Description
Download
Edwards Stokes Microvac Series - REBUILT
Instruction Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards Stokes 412J Microvac Rotary Piston Vacuum Pump - REBUILT
Stokes Microvac 412
Part Number: 900-412-014
3Ph 460V 60Hz Coil 230/460V
Stokes Microvac 412
Part Number: 900-412-015
3Ph 460V 60Hz
