Edwards STP-451 - REBUILT
Call for Price
In stock
SKU
REBUILT_STP451
| Weight | 26.45 lbs |
|---|---|
| Pumping Speed | 440 l/s |
| Ultimate Pressure | 1 x 10-9 Torr |
Edwards Seiko Seiki STP-451 Turbomolecular Vacuum Pump - REBUILT
Edwards STP-451 turbomolecular pump offers field proven reliability for use in electron microscopes, scientific instruments and semiconductor applications. Edwards rotor technology gives class-leading performance for maximum process flexibility. The STP-451 has been approved for use by major equipment manufacturers in the scientific instrument, semiconductor and magnetic media industries.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet flange | ISO-160 |
| Outlet port | KF-25 |
| Pumping speed | |
| N2 | 440 l/s |
| H2 | 275 l/s |
| Compression ratio | |
| N2 | > 108 |
| H2 | > 2 x 104 |
| Ultimate pressure | 10-7 Pa (10-9 Torr) |
| Maximum allowable inlet pressure | |
| Ambient cooled | 0.066 Pa (5 x 10-4 Torr) |
| Maximum continuous outlet pressure | |
| Ambient cooled | 13 Pa (0.1 Torr) |
| Rated speed | 48,000 rpm |
| Starting time | 3 min |
| Maximum inlet flange temperature | 120°C |
| Input voltage | 100 to 120 VAC (± 10) or |
| 200 to 240 VAC (± 10) | |
| Power consumption | |
| Start up | 0.55 kVA |
| Weight | |
| Pump | 12 kg |
| Controller | 7 kg |
| Type | Label | Description | Download |
|---|---|---|---|
|
BOC Edwards STP-301/451 Series | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards Seiko Seiki STP-451 Turbomolecular Vacuum Pump - REBUILT STP-L451C STP-H451C1
