Kinney KMBD-1600 - REBUILT
Call for Price
| Weight | 640 lbs |
|---|---|
| Motor Power | 10 hp |
| Pumping Speed | 1,600 cfm |
Kinney KMBD-1600 Mechanical Vacuum Blower - REBUILT
Kinney KMBD mechanical boosters are available in flow ranges from 400 - 12,700 cfm with mechanical noise of 82 dB(A) or less.
The Kinney KMBD-1600 is a robust and high-performance mechanical vacuum booster, engineered to enhance the efficiency and capacity of vacuum systems across a wide range of industrial applications. Manufactured by Tuthill Vacuum & Blower Systems, this booster is designed to deliver exceptional pumping speeds and lower ultimate pressures, making it an ideal choice for industries such as chemical processing, vacuum coating, pharmaceutical production, and more.
Key Features:
- High Pumping Speed: The KMBD-1600 significantly increases the throughput of primary vacuum pumps, ensuring faster processing times and improved system performance.
- Durable Construction: Built with a cast iron housing, end plates, and ductile iron rotors, the KMBD-1600 is designed to withstand demanding industrial environments and ensure long service life.
- Low Noise Operation: Operates at 82 dB(A) or less at blank-off, providing a quieter and safer working environment.
- Precision Engineering: Features heat-treated alloy steel, helical-cut gears, and precision-ground components for smooth and efficient operation.
- Oil Splash Lubrication System: Ensures consistent lubrication of internal components, reducing maintenance needs and extending operational life.
- Individually Tested: Each unit undergoes rigorous testing, including blank-off and heat run tests, to meet ISO 9001 quality standards.
The KMBD-1600 is ideal for a variety of industrial applications, including:
- Vacuum drying
- Vacuum distillation
- Freeze-drying
- Semiconductor manufacturing
- Thin-film coating
- Degassing processes
Kinney is now part of MD-Kinney, which was formerly known as Tuthill Springfield.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
- Material: Cast iron housing and end plates, ductile iron rotors, and SAE 4140 forged alloy steel drive shaft.
- Bearings: Double-row ball bearings on the gear end and single-row ball bearings on the drive shaft.
- Seals: Non-contacting slinger rotor shaft seals with optional mechanical seals available.
- Lubrication: Oil splash system for both ends.
- Noise Level: ≤82 dB(A) at blank-off.
| Type | Label | Description | Download |
|---|---|---|---|
|
Kinney KMBD Series - REBUILT | Installation Operational Maintenance Repair Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Tuthill Kinney KMBD-1600 Mechanical Vacuum Blower - REBUILT KMBD-200 200 cfm KMBD-400 400 cfm KMBD-540 540 cfm KMBD-720 720 cfm KMBD-850 850 cfm KMBD-1600 1,600 cfm KMBD-2000 2,000 cfm
