Leybold CVS60 - NEW

Name: Leybold CVS60 - NEW
Brand: Leybold
SKU: NEW_CVS60

Be the first to review this product

In stock

Only %1 left

SKU

NEW_CVS60

Request For Quote

Weight	320 lbs
Motor Power	1.2 hp
Pumping Speed	23 m³/h
Ultimate Pressure	≤ 5 x 10^-1 mbar

Description

Leybold CVS60 - 60 L Vessels Vacuum Pump - NEW

SOGEVAC Central Vacuum Stations cover the demands of numerous small vacuum consumers, increasing the availability of the vacuum service. They provide the essential performance and reliability to succeed under challenging production conditions.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Specification

Volume vacuum vessel:	60 l
Installed vacuum pump:	1 x SOGEVAC SV 25 B
Inlet connection vacuum vessel:	G 1 1/4", Inside thread
Outlet connection:	G 3/4", Inside thread
Nominal pumping speed at 50 Hz:	26 m³/h
Nominal pumping speed at 60 Hz:	31 m³/h
Pumping speed at 50 Hz:	23 m³/h
Pumping speed at 60 Hz:	25 m³/h
Ultimate total pressure without gas ballast:	≤ 0,5 mbar
Ultimate total pressure with gas ballast:	≤ 0.8 mbar
Water vapor tolerance at 50 Hz:	10 mbar
Water vapor tolerance at 60 Hz:	10 mbar
Water vapor capacity at 50 Hz:	85 g/h
Water vapor capacity at 60 Hz:	100 g/h
Operating fluid:	LVO 120
Operating fluid capacity:	0.5 l
Noise level to DIN 45 635:	64 dB(A), without gas ballast
Mains connection:	3-ph, 400 V, 50 Hz // 460 V, 60 Hz
Installed motor rating at 50 Hz:	0.9 kW
Installed motor rating at 60 Hz:	1.1 kW
Electrical control:	Basic-Controller
Admissible ambient temperature:	+12 to +40°C
Dimensions (LxBxD):	973 x 656 x 1163 mm
Weight:	145 kg / 320 lbs

Specifications

RFQ/Configuration

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Leybold CVS60 - 60 L Vessels Vacuum Pump - NEW

504309V001
504309V002
