Leybold DIVAC 1.2 L - NEW
Weight
20.5 lbs
Motor Power
0.17 hp
Pumping Speed
1.2 m3 /h
Ultimate Pressure
≤ 8 x 100 torr
Leybold DIVAC 1.2 L Dry Diaphragm Vacuum Pump - NEW
DIVAC L dual stage DIVAC L diaphragm pumps are suited for almost all requirements in the chemistry lab. They are basically corrosion and solvent resistant since their parts in contact with the pumped medium are made of PTFE (Teflon), FFPM (Kalrez) and PVDF (Solef).
Questions? send an email to our sales team!
Max. pumping speed
1.2 m3 x h-1
Ultimate pressure
≤ 8 mbar / ≤ 6 Torr
Max. exhaust back pressure
2,000 mbar / 1,500 Torr
Pump heads
2
Connection
Inlet
Hose nozzle ID 10
Exhaust
Hose nozzle ID 10
Thread
G 1/4"
Noise level
52 dB(A)
Max permissible gas admission temperature
5 to 40°C
Max permissible ambient temperature
5 to 40°C
Voltage / nominal frequency
Schuko plug
230 ± 10% V / 50 Hz
NEMA plug
115 ± 10% V / 60 Hz
NEMA plug
100 ± 10% V / 50/60 Hz
Protective class
IP44
Motor power
120 W
Current consumption
0.7 A
Motor speed
50 Hz
1,500 min-1
60 Hz
1,800 min-1
Weight
9.3 kg
Material
Pump head
PTFE
Structured diaphragm
PTFE coated
Valves
FFPM
Nozzles
PVDF
Specifications
Type
Label
Description
Download
Leybold Dry Compressing Vacuum Pumps - NEW
Excerpt / Catalog Part
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold DIVAC 1.2 L Dry Diaphragm Vacuum Pump - NEW
Part # 13506 single-phase, 230 V, 50 Hz
Part # 13508 1-phase, 100 V, 50/60 Hz
Part # 13509 1-phase, 110-120 V, 60 Hz
