Leybold DIVAC 2.2 L - NEW
Call for Price
In stock
SKU
NEW_2.2L
| Weight | 27.8 lbs |
|---|---|
| Motor Power | 0.33 hp |
| Pumping Speed | 2 m3/h |
| Ultimate Pressure | ≤ 6 x 100 torr |
Leybold DIVAC 2.2 L Dry Diaphragm Vacuum Pump - NEW
DIVAC L dual stage DIVAC L diaphragm pumps are suited for almost all requirements in the chemistry lab. They are basically corrosion and solvent resistant since their parts in contact with the pumped medium are made of PTFE (Teflon), FFPM (Kalrez) and PVDF (Solef).
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Max. pumping speed | 2.0 m3 x h-1 |
| Ultimate pressure | ≤ 8 mbar / ≤ 6 Torr |
| Max. exhaust back pressure | 2,000 mbar / 1,500 Torr |
| Pump heads | 2 |
| Connection | |
| Inlet | Hose nozzle ID 10 |
| Exhaust | Hose nozzle ID 10 |
| Thread | G 1/4" |
| Noise level | 52 dB(A) |
| Max permissible gas admission temperature | 5 to 40°C |
| Max permissible ambient temperature | 5 to 40°C |
| Voltage / nominal frequency | |
| Schuko plug | 230 ± 10% V / 50 Hz |
| NEMA plug | 115 ± 10% V / 60 Hz |
| NEMA plug | 100 ± 10% V / 50/60 Hz |
| Protective class | IP44 |
| Motor power | 245 W |
| Current consumption | 1.8 A |
| Motor speed | |
| 50 Hz | 1,500 min-1 |
| 60 Hz | 1,800 min-1 |
| Weight | 12.6 kg |
| Material | |
| Pump head | PTFE |
| Structured diaphragm | PTFE coated |
| Valves | FFPM |
| Nozzles | PVDF |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold Dry Compressing Vacuum Pumps - NEW | Excerpt / Catalog Part | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold DIVAC 2.2 L Dry Diaphragm Vacuum Pump - NEW Part # 13512 single-phase, 230 V, 50 Hz Part # 13514 1-phase, 100 V, 50/60 Hz Part # 13515 1-phase, 110-120 V, 60 Hz
