Leybold RUTA WSU 2001 / SV630B - REBUILT
In stock
SKU
REBUILT_WSU2001/SV630B
Leybold RUTA WSU 2001 / SV630B Roots Vacuum Pump System - REBUILT
SOGEVAC 2-Stage Adaptor Version
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| SOGEVAC 2-Stage |
Adaptor Version |
| Inlet connection |
DN 160 ISO-K |
| Outlet connection |
DN 100 ISO-K |
| Pumping speed at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr |
1,690 m3/h / 995 cfm |
| Ultimate partial pressure w/out gas ballast |
< 8.0 x 10-3 mbar / < 6.0 x 10-3 Torr |
| Ultimate total pressure w/ gas ballast |
< 4.0 x 10-2 mbar / < 3.0 x 10-2 Torr |
| Operating fluid |
N 62 |
| Total operating fluid capacity |
26.0 l / 27.5 qt |
Noise level to DIN 45 635 w/o gas ballast
at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr |
80 dB(A) |
| Mains connection |
3-ph, 400 V, 50 Hz |
| Installed motor rating |
22.5 kW / 30.6 hp |
Power consumption
at 1.0 x 10-1 mbar / 7.5 x 10-2 Torr |
16.5 kW / 22.4 hp |
| Admissible ambient temperature |
+12 to +40°C / +54 to +104°F |
| Weight |
1,140 kg / 2,514 lbs |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
