Leybold RUVAC WA / WAU 2001 - NEW
Call for Price
In stock
SKU
NEW_WAWAU2001
| Weight | 896 lbs |
|---|---|
| Motor Power | 10 hp |
| Pumping Speed | 2050 m3/h |
| Ultimate Pressure | < 3 x 10-2 Torr |
Leybold RUVAC WA / WAU 2001 Roots Vacuum Blower - NEW
- Connection flange: DN 160 PN6
- Max. permissible pressure difference: 50 mbar
- Rotational speed (50/60 Hz): 3,000 / 3,600 min-1
- Nom. pumping speed (50 Hz): 2,050 m3 · h-1
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal pumping speed | 2,050 m3 · h-1 |
| Max. pumping speed | 1850 m3 · h-1 |
| Nominal pumping speed at 60 Hz | 2460 m3 · h-1 |
| Max. pumping speed at 60 Hz | 2100 m3 · h-1 |
| Ultimate total pressure | < 4 x 10-2 mbar |
| Maximum allowable pressure differential in continous operation |
50 mbar |
| Leak rate, integral | ≤ 5 · 10-4 mbar · l · s-1 |
| Permissible ambient temperatures | 12 - 40 °C |
| Main supply IEC motor | 380-420 YY/Y V |
| Motor power, 50 Hz | 7.5 kW |
| Nominal speed, 50/60 Hz | 3000 / 3600 min-1 |
| Max. permissible speed | 3600 min-1 |
| Motor protection category | 55 IP |
| Weight WS / WSU | 406 kg/ 896 lbs |
| Collar flanges | 160 ISO · K |
| Noise level | < 80 |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold RUVAC Series - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold RUVAC WA / WAU 2001 Roots Vacuum Blower - NEW Part no. 11750 / 117 50 Pumping speed: 2,050 m3/h Ultimate pressure: < 4 x 10-2 mbar Three-phase motor: 380-420V, 50Hz / 380-480V, 60Hz Part no. 11254 / 112 54 Pumping speed: 2,050 m3/h Ultimate pressure: < 4 x 10-2 mbar w/out motor Part no. 11751 / 117 51 Pumping speed: 2,050 m3/h Ultimate pressure: < 4 x 10-2 mbar 3-phase motor: 380-420V, 50Hz / 380-480V, 60Hz Part no. 11851 / 118 51 Pumping speed: 2,050 m3/h Ultimate pressure: < 4 x 10-2 mbar 3-phase motor: 380-420V, 50Hz / 380-480V, 60Hz Part no. 11322 / 113 22 Pumping speed: 2,050 m3/h Ultimate pressure: < 4 x 10-2 mbar w/out motor Operating fluid: LEYBONOL LVO 100 Replaced Part #: 91751-1
