Leybold RUVAC WH / WHU 2500 - REBUILT
| Weight |
905 lbs |
| Motor Power |
8.4 hp |
| Pumping Speed |
2,500 m3/h |
| Ultimate Pressure |
7.5 x 101 mbar |
Leybold RUVAC WH / WHU 2500 Roots Vacuum Blower - REBUILT
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal pumping speed |
50 Hz: 2,500 m3 x h-1 |
60 Hz: 3,000 m3 x h-1 |
| Max. effective pumping speed w/ backing pump |
50 Hz: 2,200 m3 x h-1 |
60 Hz: 2,500 m3 x h-1 |
| Max. permissible pressure difference during continuous operation |
50 Hz: 50 to 75 mbar |
60 Hz: 40 to 60 mbar |
| Leak rate, integral |
1 x 10-5 |
| Nominal power rating |
FC : 11.0 kW |
WH: 6.5 kW |
WHU: 15.0 kW |
| Idle mode power consumption |
0.7 kW |
| Energy efficiency class |
IE 2 |
| Nominal speed |
50 Hz: 3,000 rpm / 60 Hz: 3,600 rpm |
| Max. permissible speed |
6,000 rpm |
| Energy efficiency class |
IE 2 |
| Nominal speed, approx. |
50 Hz: 3,000 rpm |
60 Hz: 3,600 rpm |
| Max. permissible speed |
6,000 rpm |
| Type of protection |
IP 54/55 |
| Cooling water connection |
1/4", female |
| Cooling water quantity |
1 to 3 l/min |
| Cooling water admission temperature |
+5 to +35°C |
| Permissible cooling water temperature |
2 to 6 bar |
| Inlet flange |
ISO-K 250 |
| Outlet flange |
ISO-K 100 |
| Lubricant |
1.2 l |
| Weight |
861 / 905 hp |
| Noise level |
< 63 dB(A) |
Specifications
| Type |
Label |
Description |
Download |
|
|
Leybold RUVAC WH / WHU Series - REBUILT |
Instruction Manual |
Download
|
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold RUVAC WH / WHU 2500 Roots Vacuum Blower - REBUILT
155250V / 155 250V WH 2500 400 V GS LVO 410 11 kW (100 Hz)
155251V / 155 251V WH 2500
155252V / 155 252V WH 2500
155253V / 155 253V WH 2500
155254V / 155 254V WH 2500
155260V / 155 260V WH 2500
155261V / 155 261V WH 2500
155262V / 155 262V WH 2500
155263V / 155 263V WH 2500
155264V / 155 264V WH 2500
155265V / 155 265V WH 2500
155267V / 155 267V WH 2500
155270V / 155 270V WH 2500
155271V / 155 271V WH 2500
155272V / 155 272V WH 2500
155273V / 155 273V WH 2500
155280V / 155 280V WHU 2500
155281V / 155 281V WHU 2500
155284V / 155 284V WHU 2500
155285V / 155 285V WHU 2500
155288V / 155 288V WHU 2500
