Leybold RUVAC WS / WSU 1001 - REBUILT
Weight
514 lbs
Motor Power
4 hp
Pumping Speed
1,000 m3 /h
Ultimate Pressure
< 4 x 10-2 mbar
Leybold RUVAC WS / WSU 1001 Roots Vacuum Blower - REBUILT
The WS and WSU models have a canned motor for a tight vacuum seal on the motor can; you do not need to worry about a shaft seal leak. If you do not order this blower with a bypass you need a vacuum switch. Please select standard vertical flow feet configuration or horizontal flow.
Questions? send an email to our sales team!
Nominal pumping speed
50 Hz: 1,000 m3 x h-1 3 x h-1
Max. effective pumping speed w/ backing pump
50 Hz: 800 m3 x h-1 3 x h-1
Ultimate total pressure
< 4 x 10-2
Max. permissible pressure difference during continuous operation
80.0 mbar
Leak rate, integral
< 1 x 10-4 mbar x l/s
Mains supply
50 Hz: 200/230/400 V
Thermal class
F
Permissible ambient temperatures
+5 to +40°C
Motor power
4.0 kW
Energy efficiency class
IE 2
Nominal speed, approx.
50 Hz: 3,000 rpm
Max. permissible speed
6,000 rpm
Type of protection
IP 20
Connection flanges
DN 100 ISO-K
Noise level
< 60 dB(A)
Weight
228 - 233 kg / 502 - 514 lbs
Specifications
Type
Label
Description
Download
Leybold RUVAC WS / WSU Series - REBUILT
Instruction Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold RUVAC WS / WSU 1001 Roots Vacuum Blower - REBUILT
91742 / 917 42 WS 1001
91743 / 917 43 WSU 1001
91747 / 917 47 WS 1001 PFPE
91748 / 917 48 WSU 1001 PFPE
11742 / 117 42 WS 1001
10183 / 101 83 WS 1001 Anderol 555
11747 / 117 47 WS 1001 PFPE
11743 / 117 43 WSU 1001
170168 / 170 168 WSU 1001 horizontal, HC, 4" ANSI, 460/3/50
11843 / 118 43 WSU 1001 H horizontal
167043 / 167 043 WSU 1001 H horizontal
15047 / 150 47
