Leybold SOGEVAC NEO D 25 - NEW
| Weight | 110 lbs |
|---|---|
| Motor Power | 1.2 hp |
| Pumping Speed | 28 m3/h |
| Ultimate Pressure | < 8 x 10-3 mbar |
Leybold SOGEVAC NEO D 25 Rotary Vane Vacuum Pump - NEW
The NEW generation of SOGEVAC vacuum pumps. Triple-hitting vacuum technology for a cleaner, quieter, longer-running performance.
Pairing health and safety with efficient processes is a vital need for any workplace, from research labs to industrial manufacturers. When processes rely on continuous vacuum, choosing the right components becomes all the more essential. Reliable, high-performance vacuum technology not only gets the job done, but also contributes to a better work environment with less noise and fewer emissions. The result is greater well-being and peace of mind – for higher employee productivity and precision in demanding applications. When it comes to these universal challenges, the new SOGEVAC NEO D rotary vane vacuum pump offers a bundle of advantages. But most of all, it is cleaner, quieter and virtually maintenance-free.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| SOGEVAC NEO D 25 | 970202V | 970201V | 970200V |
|---|---|---|---|
| Inlet / outlet connection | DN 25 ISO-KF | ||
| Nominal pumping speed 50 Hz | 28 m3h / 16.48 cfm | ||
| Nominal pumping speed 60 Hz | 34 m3h / 20.01 cfm | ||
| Pumping speed 50 Hz | 24 m3h / 14.13 cfm | ||
| Pumping speed 60 Hz | 29 m3h / 17.07 cfm | ||
| Ultimate partial pressure w/out gas ballast | ≤ 0.008 mbar / ≤ 0.006 Torr | ||
| Ultimate total pressure w/ gas ballast | ≤ 0.1 mbar / ≤ 0.075 Torr | ||
| Water vapor tolerance 50/60 Hz | 10 mbar / 7.5 Torr | ||
| Operating fluid | LVO 700 | ||
| Operating fluid capacity | 1.5 liters / 1.32 qt | ||
| Noise level to DIN 45 635 w/out gas ballast | 54 dB(A) | ||
| Mains connections | 3-phase 180-264V 342-457V 50 Hz 180-264V 342-506V 60 Hz |
1?phase 200-240V ±10% 50/60 Hz | 1?phase 240V ±10% 50/60 Hz |
| Motor rating 50 Hz | 900 W | ||
| Motor rating 60 Hz | 1,100 W | ||
| Rotation speed 50 Hz | 1,458 min-1 / 1,458 rpm | 1,460 min-1 / 1,460 rpm | |
| Rotation speed 60 Hz | 1,764 min-1 / 1,764 rpm | 1,730 min-1 / 1,730 rpm | |
| Motor protection rating | IP 55 | IP 40 | |
| Admissible ambient temperature | +12 to +40°C / +54 to +104°F | ||
| Weight | 50 kg / 110 lbs | ||
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold Oil Sealed - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SOGEVAC NEO D 25 Rotary Vane Vacuum Pump - NEW 970202V three-phase 180-264V 342-457V 50Hz / 180-264V 342-506V 60Hz 970201V single-phase 180-264V 50/60Hz 970200V 1-phase 180-264V 50/60Hz Operating fluid: LEYBONOL LVO 700
