Leybold SOGEVAC SV 16 B - NEW
Starting at
$1,808
In stock
Only %1 left
SKU
NEW_SV16B
| Weight | 45 lbs |
|---|---|
| Motor Power | 0.74 hp |
| Pumping Speed | 15 m3/h |
| Ultimate Pressure | ≤ 1 x 100 mbar |
Leybold SOGEVAC SV 16 B Rotary Vane Vacuum Pump - NEW
The new SOGEVAC range of rotary vane vacuum pumps is setting new standards and offers following major characteristics:
- Operating fluid: LEYBONOL LVO 120
- Pumping speed (50 Hz): 15 m³/h
- Pumping speed (60 Hz): 17 m³/h
- Ultimate pressure: 1 mbar
- Compact design and small footprint
- Very low and constant noise level in any working condition
- Integrated functions, no external pipe
- No motor coupling up to SV65 B
- Variant concept / specific customer configurations
- ATEX versions for categories 2 and 3, from SV40 B to SV100 B
- Simplified maintenance
All this without any concession to the high technical performance of the SOGEVAC pumps such as ultimate pressure, pump-down time, water vapor tolerance…
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal Speed | ||
| 50 Hz | 16 m3 x h-1 | 9.4 cfm |
| 60 Hz | 19 m3 x h-1 | 11.2 cfm |
| Pumping speed | ||
| 50 Hz | 15 m3 x h-1 | 8.8 cfm |
| 60 Hz | 17 m3 x h-1 | 10 cfm |
| Ultimate total pressure w/out gas ballast | ≤ 1 mbar | |
| Ultimate total pressure w/ gas ballast | ≤ 2 mbar | |
| Water vapor tolerance | 10 mbar | |
| Water vapor capacity | 30 g x h-1 | |
| Oil capacity | 0.5 l | |
| Noise level | 66 dBA | |
| Admissible ambient temperature | 12 to 40°C / 54 to 104°F | |
| Motor power | 0.55 kW | |
| Nominal speed | 3,000 min-1 | |
| Type of protection | IP 55-F | |
| Weight | 20.5 kg / 45 lbs | |
| Connections | ||
| Intake, thread | 3/4" G or NPT |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold Oil Sealed - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SOGEVAC SV 16 B Rotary Vane Vacuum Pump - NEW Part no. 960160 / 960 160 Pumping speed: 15 m3/h Ultimate pressure: < 1.0 mbar Three-phase motor: 220-240/380-415V, 50Hz // 220-266/380-460V, 60Hz w/ gas ballast valve Part no. 960175 / 960 175 Pumping speed: 15 m3/h Ultimate pressure: < 1.0 mbar 3-phase motor: 200V, 50/60Hz w/ gas ballast valve Part no. 960165 / 960 165 Pumping speed: 15 m3/h Ultimate pressure: < 1.0 mbar Single-phase motor: 230V, 50/60Hz w/ gas ballast valve Part no. 960170 / 960 170 Pumping speed: 15 m3/h Ultimate pressure: < 1.0 mbar 1-phase motor: 110-120V, 60Hz w/ gas ballast valve Part no. 960174 / 960 174 Pumping speed: 15 m3/h Ultimate pressure: < 1.0 mbar 1-phase motor: 100V, 50/60Hz w/ gas ballast valve Operating fluid: LEYBONOL LVO 120
