Leybold SOGEVAC SV 40 BI - NEW
Call for Price
In stock
SKU
NEW_SV40BI
| Weight | 95 lbs |
|---|---|
| Motor Power | 1.5 hp |
| Pumping Speed | 40 m3/h |
| Ultimate Pressure | ≤ 5 x 10-2 mbar |
Leybold SOGEVAC SV 40 BI Rotary Vane Vacuum Pump - NEW
The SOGEVAC BI pumps offers beside the well proven advantages of the SOGEVAC B series additionally a one decade better ultimate pressure compared to the B pumps and a high pumping speed stability at low pressure. Thus these pumps can be used as backing pump for some high vacuum pump systems.
- Operating fluid: LEYBONOL LVO 120
- Pumping speed (50 Hz): 40 m³/h
- Pumping speed (60 Hz): 48 m³/h
- Ultimate pressure: 0.05 mbar
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet connection | DN 40 ISO-KF |
| Outlet connection | DN 40 ISO-KF |
| Nominal pumping speed | 50.0 m3/h |
| Pumping speed | 50.0 m3/h |
| Ultimate partial pressure w/out gas ballast | < 0.5x10-2 mbar |
| Ultimate total pressure w/out gas ballast | - |
| Ultimate total pressure w/ gas ballast | < 5.0 x 10-3 mbar |
| Water vapor tolerance | - |
| Water vapor capacity at 50/60 Hz | - |
| Operating fluid capacity | |
| min. | 1.0 l |
| max. | 1.0 l |
| Motor rating | 1.3 kW |
| Rotation speed | 1,800 min-1 |
| Motor protection rating | IP55-F |
| Shipping weight | 43 kg (95m lbs) |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold Oil Sealed - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SOGEVAC SV 40 BI Rotary Vane Vacuum Pump - NEW Part no. 960330 / 960 330 Pumping speed: 40 m3/h Ultimate pressure: < 5 x 10-2 mbar Three-phase motor: 230/400V, 50Hz // 460V, 60Hz w/out gas ballast valve Part no. 960331 / 960 331 Pumping speed: 40 m3/h Ultimate pressure: < 5 x 10-2 mbar 3-phase motor: 230/400V, 50Hz // 460V, 60Hz w/ small gas ballast valve Operating fluid: LEYBONOL LVO 120
