Leybold SOGEVAC SV 750 B - NEW

$0
In stock
Only %1 left
SKU
NEW_SV750B
Weight 1653.5 lbs
Motor Power 25 hp
Pumping Speed 755 m3/h
Ultimate Pressure ≤ 8 x 10-2 mbar

Leybold SOGEVAC SV 750 B/BF Rotary Vane Vacuum Pump - NEW

The new SOGEVAC range of rotary vane vacuum pumps is setting new standards and offers following major characteristics:

  • Operating fluid: LEYBONOL LVO 130
  • Pumping speed (50 Hz): 755 m³/h
  • Ultimate pressure: ≤ 0.7 mbar
  • Compact design and small footprint
  • Very low and constant noise level in any working condition
  • Integrated functions, no external pipe
  • No motor coupling up to SV 65 B
  • Variant concept / specific customer configurations
  • ATEX versions for categories 2 and 3, from SV 40 B to SV 100 B
  • Simplified maintenance

All this without any concession to the high technical performance of the SOGEVAC pumps such as ultimate pressure, pump-down time, water vapor tolerance…

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Nominal Speed
    50 Hz 840 m3 x h-1 494.4 cfm
Pumping speed
    50 Hz 755 m3 x h-1 444.4 cfm
Ultimate total pressure w/o gas ballast ≤ 8 x 10-2
Ultimate total pressure w/ gas ballast ≤ 0.7 mbar
Ultimate total pressure w/ 2 gas ballast valves     ≤ 2.0 mbar
Cooling air
Motor power 18.5 kW 25 hp
Oil filing, min/max 20/23 l
Noise level 72 dBA
Oil type mineral oil LVO 130
Weight 750 kg / 1653.5 lbs

Specifications

Type Label Description Download
Leybold Oil Sealed - NEW Instruction Manual Download

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Leybold SOGEVAC SV 750 B/BF Rotary Vane Vacuum Pump - NEW

Part no. 960875
Pumping speed: 755 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
Three-phase motor: 380/400/415/690V, 50Hz
air-cooled
Operating fluid: LEYBONOL LVO 130

BF Part no. 960877
Pumping speed: 755 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: 380/400/415/690V, 50Hz
water-cooled
Operating fluid: LEYBONOL LVO 130

ATEX Part no. DU0004
Pumping speed: 755 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: upon request
Marking: II (i) 2G b IIB+H2 T3 / (o) 2G IIC T3 (10°C
w/ gas ballast valve
Operating fluid: LEYBONOL LVO 210

BF ATEX Part no. DU0005
Pumping speed: 755 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: upon request
Marking: II (i) 2G b IIB+H2 T3 / (o) 2G IIC T4 (10°C
w/ gas ballast valve
Operating fluid: LEYBONOL LVO 210

ATEX Part no. DU0006
Pumping speed: 755 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: upon request

BF ATEX Part no. DU0007
Pumping speed: 755 m3/h
Ultimate pressure: ≤ 8 x 10-2 mbar
3-phase motor: upon request
