Leybold SOGEVAC SV120BIFC - REBUILT
Call for Price
In stock
SKU
REBUILT_SV120BIFC
| Weight | 207 lbs |
|---|---|
| Motor Power | 3.22 hp |
| Pumping Speed | 110 m3/h |
| Ultimate Pressure | ≤ 5 x 10-1 mbar |
Leybold SOGEVAC SV120BIFC Rotary Vane Vacuum Pump - REBUILT
The new SOGEVAC range of rotary vane vacuum pumps is setting new standards and offers following major characteristics:
- Operating fluid: LEYBONOL LVO 130
- Pumping speed (50 Hz): 110 m³/h
- Pumping speed (60 Hz): 120 m³/h
- Ultimate pressure: 0.5 mbar
- Compact design and small footprint
- Very low and constant noise level in any working condition
- Integrated functions, no external pipe
- No motor coupling up to SV65B
- Variant concept / specific customer configurations
- ATEX versions for categories 2 and 3, from SV40B to SV100B
- Simplified maintenance
All this without any concession to the high technical performance of the SOGEVAC pumps such as ultimate pressure, pump-down time, water vapor tolerance…
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal Speed | 130 m3 x h-1 |
| Pumping speed | 110 m3 x h-1 |
| Ultimate partial pressure w/o gas ballast | ≤ 0.5 mbar |
| Ultimate total pressure with standard gas ballast | ≤ 1.5 mbar |
| Water vapor tolerance w/ standard gas ballast | 30 mbar |
| Permissible water vapor load | 1.6 kg x h-1 |
| Motor power | 2.4 kW |
| Rated rotational speed | 1,500 min-1 |
| Noise level | 61 dBA |
| Oil capacity | 2 l |
| Weight | 94 kg / 207 lbs |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold SOGEVAC SV120BIFC Rotary Vane Vacuum Pump - REBUILT
