Leybold TRIVAC D16A - REBUILT
Weight
85 lbs
Motor Power
1 hp
Pumping Speed
400 l/m
Ultimate Pressure
3 x 10-4 Torr
Leybold TRIVAC D16A Rotary Vane Vacuum Pump - REBUILT
If the requested voltage is not in stock then we will purchase a new motor and split the cost with you. They run on various vacuum pump oils . PTB Sales' technicians rebuild pumps to OEM specifications led by a Leybold Vacuum factory-trained mechanic. We also offer repair service .
Leybold blower packages are available.
Questions? send an email to our sales team!
Displacement
14.1 cfm
400 l/min
Ultimate partial pressure
3 x 10-4 Torr
Ultimate partial pressure w/ gas ballast
3 x 10-3 Torr
Water vapor tolerance
15 Torr
Oil capacity
1 qt
4.2 lbs
Motor power
1 hp
Rotational speed
1,725 rpm
Weight
85 lb
Sound pressure level (max) at 3 feet w/ gas ballast open
60 dB(A)
Sound pressure level (ave) at 3 feet w/ gas ballast open
57 dB(A)
Intake & exhaust connections
KF25
Max. ambient temperature
104°F
Specifications
Type
Label
Description
Download
Leybold-Heraeus TRIVAC A Series - REBUILT
Operating Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TRIVAC D16A Rotary Vane Vacuum Pump - REBUILT
