Leybold TRIVAC NT16 - REBUILT
Call for Price
In stock
SKU
REBUILT_NT16
| Weight | 88 lbs |
|---|---|
| Motor Power | 0.88 hp |
| Pumping Speed | 16.5 m3/h |
| Ultimate Pressure | < 2 x 10-3 mbar |
Leybold TRIVAC NT16 Rotary Vane Vacuum Pump - REBUILT
If the requested voltage is not in stock then we will purchase a new motor and split the cost with you. They run on various vacuum pump oils. PTB Sales' technicians rebuild pumps to OEM specifications led by a Leybold Vacuum factory-trained mechanic. We also offer repair service.
Leybold blower packages are available.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Nominal pumping speed | 50 Hz: 18.9 m3h-1 60 Hz: 29.5 m3 x h-1 |
| Pumping speed | 50 Hz: 16.5 m3h-1 60 Hz: 25.7 m3h-1 |
| Ultimate partial pressure w/out gas ballast | |
| w/ mineral oil | 10-4 mbar |
| w/ PFPE | 8 x 10-4 mbar |
| Ultimate total pressure w/out gas ballast | |
| w/ mineral oil | < 2 x 10-3 mbar |
| w/ DOT | 0.6 mbar |
| Ultimate total pressure w/ gas ballast | |
| w/ mineral oil | 5 x 10-3 mbar |
| w/ PFPE | 5 x 10-3 mbar |
| w/ DOT | 0.9 mbar |
| Water vapor tolerance | 25 mbar |
| Water vapor capacity | 305 g x h-1 |
| Oil filling, min/max | 0.7/ 1.0 l |
| Noise level | < 54 dB(A) |
| Admissible ambient temp. | 12 - 40°C |
| Motor rating | 550/660 W |
| Nominal speed | 1,500 min-1 |
| Type of protection | 44 for 1-phase motor / 55 for 3-phase motor |
| Weight | 40 kg |
| Connections, intake & exhaust | DN 25 KF |
| Type | Label | Description | Download |
|---|---|---|---|
|
Oerlikon Leybold TRIVAC NT16 / NT25 - REBUILT | Operating Instruction | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TRIVAC NT16 Rotary Vane Vacuum Pump - REBUILT 140220 / 140 220 1-phase world motor, filling w/ mineral oil 140231 / 140 231 1-phase EU motor, filling w/ mineral oil 140232 / 140 232 1-phase EU motor, filling w/ GS 555 140233 / 140 233 1-phase EU motor, filling w/ PFPE 140234 / 140 234 1-phase EU motor, filling w/ DOT 4 140235 / 140 235 1-phase EU motor, filling w/ RCF E 68N 140241 / 140 241 1-phase US/Japan motor, filling w/ mineral oil 140221 / 140 221 3-phase world motor, filling w/ mineral oil 140222 / 140 222 3-phase world motor, filling w/ GS 555 140223 / 140 223 3-phase world motor, filling w/ PFPE 140224 / 140 224 3-phase world motor, filling w/ DOT 4 140225 / 140 225 3-phase world motor, filling w/ RCF E 68N
