Leybold TURBOVAC 1100 C - REBUILT
Call for Price
In stock
Only %1 left
SKU
REBUILT_TMP1100C
| Weight | 48 lbs |
|---|---|
| Pumping Speed | 710 l/s |
| Ultimate Pressure | 3 x 10-10 mbar |
Leybold Vacuum TURBOVAC 1100 C Turbomolecular Pump - REBUILT
Sold with a one year warranty. We offer repair service and are capable of rebuilding, balancing and testing this pump. View our inventory of Leybold Vacuum turbo pumps.
Typical Applications
- Data storage
- Flat panel displays
- Optical coating
- Large area coating
- R & D: Fusion experiments, space simulation
- Load locks and transfer chambers
Technical Features
- Robust rotor design
- Installation in any orientation
- Highest pumping speed and throughput
- Bearing temperature measurement through the TURBO.DRIVE TD 20 classic
- Oil-free pump for generating clean high and ultrahigh vacuum conditions
Advantages to the User
- Space-saving
- Easy to integrate into complex vacuum systems
- High productivity
- Low operating costs
- Highly reliable operation also in processes loaded with particles
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet flange | DN 160 ISO-K | DN 200 ISO-K | DN 250 ISO-K |
| Pumping speed | |||
| N2 l/s | 710 | 830 | 1,050 |
| Ar l/s | - | 760 | 980 |
| He l/s | - | 750 | 850 |
| H2 l/s | - | 600 | 630 |
| Max. gas throughput | |||
| N2 mbar x l/s | 6.5 | ||
| Ar mbar x l/s | 6.5 | ||
| Compression ratio | |||
| N2 | 1 x 105 | ||
| Ar | 1 x 105 | ||
| H2 | 1 x 104 | ||
| Ultimate pressure mbar (Torr) | < 3 x 10-10 (< 2.2 x 10-10) | ||
| Run-up time at 95% speed of nominal speed | 9 min | ||
| Max. foreline pressure for N2 mbar (Torr) | 0.1 (0.075) | ||
| Foreline connection | KF40 | ||
| Mounting position | Any | ||
| Bearing type | Grease/ceramic ball bearing | ||
| Corrosive version (C) | Yes | ||
| Cooling | Standard: Water • Available: Air | ||
| Recommended forevacuum pump | TRIVAC D 65 B / SCROLLVAC SC 15 / 30 D | ||
| Purge / vent port | DN 10 KF | ||
| Cooling water connection (hose nozzles) | 10 mm (0.39 in) | ||
| Weight | 22 kg (48 lbs) | ||
| Frequency converter | TD 20, NT 20, NT 1000/1500 | ||
Specifications
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold TURBOVAC 1100 C - REBUILT | Operating Instructions | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC 1100 C Turbomolecular Pump - REBUILT Part no. 800150V0030 Pumping speed: 710 l/s (Nitrogen) Ultimate pressure: < 3 x 10-10 mbar Connecting flange high-vacuum: DN 160 ISO-K Connecting flange fore-vacuum: DN 63 ISO-K water-cooled Part no. 800150V0031 Pumping speed: 830 l/s (Nitrogen) Ultimate pressure: < 3 x 10-10 mbar Connecting flange high-vacuum: DN 200 ISO-K Connecting flange fore-vacuum: DN 63 ISO-K water-cooled Part no. 800150V0032 Pumping speed: 1,050 l/s (Nitrogen) Ultimate pressure: < 3 x 10-10 mbar Connecting flange high-vacuum: DN 250 ISO-K Connecting flange fore-vacuum: DN 63 ISO-K water-cooled
