Leybold TURBOVAC 361 - REBUILT
Weight
26.00 lbs
Pumping Speed
345 l/s-1
Ultimate Pressure
< 1 x 10-10 mbar
Leybold Vacuum TURBOVAC 361 Turbomolecular Pump - REBUILT
Most configurations are being sold discounted while supplies last.
Sold with one year warranty. The 361C corrosive version is also available; please call for a quote and lead time. We offer repair service and are capable of rebuilding, balancing and testing this pump. View our inventory of Leybold Vacuum turbo pumps .
Typical Applications
Leak detectors
Mass spectrometers
Data storage
Optical coating
R & D: UHV systems, Particle accelerators
Load locks and transfer chambers
Technical Features
Small footprint
Installation in any orientation
Oil-free pump for generating clean high and ultrahigh vacuum conditions
Bearing temperature measurement through the TURBO.DRIVE TD 20 classic
Advantages to the User
Space-saving
Easy to integrate into complex vacuum systems
Low operating costs
Highly reliable operation also in processes loaded with particles
Questions? send an email to our sales team!
Inlet flange
DN 100 ISO-K • 100 CF
DN 160 ISO-K • 160 CF
Pumping speed
N2 l/s
345
400
Ar l/s
350
-
He l/s
340
380
H2 l/s
340
370
Max. gas throughput
N2 mbar x l/s
3.0
Ar mbar x l/s
2.5
Compression ratio
N2
1 x 109
He
6 x 104
H2
3 x 103
Ultimate pressure mbar (Torr)
< 1 x 10-10 (< 0.75 x 10-10 )
Ultimate partial pressure mbar
< 10-10
Max. continuous inlet pressure mbar (Torr)
5 x 10-2 (4 x 10-2 )
Max. foreline pressure for N2 mbar (Torr)
5 x 10-1 (4 x 10-1 )
Foreline connection
KF25, ISO 63
Mounting position
Any
Bearing type
Grease/ceramic ball bearing
Corrosive version (C)
Yes
Cooling
Standard: Water • Available: Air
Recommended forevacuum pump
Standard: TRIVAC D 16 B • Corrosive: D 25 B
Run-up time at 95% speed
2 min
Purge / vent port
DN 10 KF
Cooling water connection (hose nozzles)
10 mm (0.39 in)
Weight
12 kg (26 lbs)
Max. power consumption / Ultimate pressure
680 / 480 VA
Frequency converter
TD 20 , NT 20 , NT 150/360
Specifications
Type
Label
Description
Download
Leybold TURBOVAC 50 to 1000 - REBUILT
Operating Instructions
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC 361 Turbomolecular Pump - REBUILT
85670 / 856 70 TURBOVAC 361 DN 100 ISO-K
85671 / 856 71 TURBOVAC 361 DN 100 CF
85672 / 856 72 TURBOVAC 361 DN 160 ISO-K
85673 / 856 73 TURBOVAC 361 DN 160 CF
