Leybold TURBOVAC 850 i / iX - NEW
Call for Price
In stock
SKU
NEW_TV850i/iX
| Weight | 20 lbs |
|---|---|
| Pumping Speed | 720 l/s |
| Ultimate Pressure | < 3.5 x 10-8 mbar |
Leybold TURBOVAC 850 i / iX Turbomolecular Vacuum Pump - NEW
The TURBOVAC i / iX family has grown and now has two further members. The new TURBOVAC 850 i / iX and TURBOVAC 950 i / iX offer additional pump sizes with significantly higher pumping speeds than previously available, enabling customers to take advantage in more applications. That‘s why you can always rely on TURBOVAC i / iX!
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet high-vacuum connection | DN 160 ISO-K / CF |
| Outlet fore-vacuum connection | DN 25 KF |
| Pumping speed l/s | |
| N2 | 720 |
| Ar | 655 |
| He | 850 |
| H2 | 755 |
| Gas throughput mbar x l/s | |
| N2 | 14 |
| Ar | 3.5 |
| He | 21 |
| H2 | > 15 |
| Compression ratio | |
| N2 | > 1 x 1011 |
| Ar | > 1 x 1011 |
| He | 1.3 x 108 |
| H2 | 4.4 x 106 |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TURBOVAC 850 i / iX Turbomolecular Vacuum Pump - NEW 840071V1000 850 i 160 ISO-K 840071V2000 850 i ABus/160 ISO-K 840081V1000 850 i 160 CF 840081V2000 850 i ABus/160 CF 840071V3000 850 iX ABus/160 ISO-K 840071V3300 850 iX RS485/160 ISO-K 840081V3000 850 iX ABus/160 CF 840081V3300 850 iX RS485/160 CF
