Leybold TURBOVAC MAG W 300 P - NEW
Call for Price
| Weight | 28.66 lbs |
|---|---|
| Pumping Speed | 300 l/s |
| Ultimate Pressure | < 1 x 10-8 mbar |
Leybold TURBOVAC MAG W 300 P Turbomolecular Vacuum Pump - NEW
The TURBOVAC MAG turbomolecular vacuum pumps with magnetic rotor suspension pressure range from 10-1 mbar (0.75 x 10-1 Torr) to 10-10 mbar (0.75 x 10-10 Torr). Pumping speeds for air vary from 300 l/s to 3,200 l/s. The TURBOVAC MAG pumps are used in applications where low noise level, extremely low vibration or hydrocarbon-free vacuum conditions are important. As well in applications with corrosive gases or for analytical instruments and research and development.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet connection | DN 100 ISO-K |
| Outlet connection | DN 16 ISO KF |
| Pumping speed | |
| N2 | 300 l/s |
| Ar | 260 l/s |
| He | 260 l/s |
| H2 | 190 l/s |
| Gas throughput | |
| N2 | 7.0 mbar x l/s |
| Compression ratio | |
| N2 | 1.0 x 1010 |
| He | 9.2 x 104 |
| H2 | 3.2 x 103 |
| Ultimate pressure | < 1.0 x 108 mbar |
| Max. foreline pressure for N2 | 8.0 mbar |
| Nominal rotational speed | 58,800 min-1 |
| Run up time | 5 min |
| Max. power consumption | 400 W |
| Power consumption at ultimate pressure | 120 W |
| Protection rating | IP 30 |
| Admissible ambient temperature | 10 - 40°C |
| Cooling standard | Convection |
| Cooling optional | Air / Water |
| Cooling water consumption | 60 l.h |
| Permissible cooling water temperature | 15 - 25°C |
| Weight | 13 kg |
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold High Vacuum - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold TURBOVAC MAG W 300 P Turbomolecular Vacuum Pump - NEW Part no. 410300V0005 Pumping speed: 300 l/s (Nitrogen) Ultimate pressure: < 1 x 10-8 mbar Connecting flange high-vacuum: DN 100 ISO-K Connecting flange fore-vacuum: DN 16 ISO-KF (clamped) convection-cooled Part no. 410300V0006 Pumping speed: 300 l/s (Nitrogen) Ultimate pressure: < 1 x 10-10 mbar Connecting flange high-vacuum: DN 100 CF Connecting flange fore-vacuum: DN 16 ISO-KF (clamped) convection-cooled
-
