Leybold TURBOVAC T 1600 - REBUILT
Call for Price
In stock
SKU
REBUILT_T1600
| Weight | 173.00 lbs |
|---|---|
| Pumping Speed | 1100 l/s |
| Ultimate Pressure | 3 x 10-10 mbar |
Leybold Vacuum TURBOVAC T 1600 Turbomolecular Pump - REBUILT
Sold with a one year warranty. We offer repair service and are capable of rebuilding, balancing and testing this pump. View our inventory of Leybold Vacuum turbo pumps.
Typical Applications
- Data storage
- Flat panel displays
- Optical coating
- Large area coating
- R & D: Thermonuclear fusion experiments, space simulation
Technical Features
- Frequency converter and power supply integrated
- Robust rotor design
- Operation in any orientation
- Highest pumping speed and highest throughput
- Oil-free pump for generating clean high and ultrahigh vacuum conditions
- Purge gas and venting valve integrated
- For special outside influences: tropical proof moisture resistant (only T 1601)
Advantages to the User
- Space-saving
- Easy to integrate into complex vacuum systems
- High productivity
- Low operating costs
- Highly reliable operation also in processes loaded with particles
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Inlet flange | DN 200 ISO-F | DN 250 ISO-F • 250 CF |
| Pumping speed | ||
| N2 l/s | 1,100 | 1,550 |
| Ar l/s | 960 | 1,410 |
| He l/s | 1,150 | 1,300 |
| H2 l/s | 690 | 720 |
| Max. gas throughput | ||
| N2 mbar x l/s | 30 | |
| Ar mbar x l/s | 20 | |
| He mbar x l/s | 30 | |
| H2 mbar x l/s | 20 | |
| Compression ratio | ||
| N2 | 5 x 105 | |
| Ar | 1 x 106 | |
| He | 1 x 104 | |
| H2 | 2 x 102 | |
| Ultimate pressure mbar (Torr) | < 3 x 10-10 (< 2.2 x 10-10) | |
| Max. foreline pressure for N2 mbar (Torr) | 0.5 (0.375) | |
| Recommended forevacuum pump (alternatively) | ||
| Run-up time at 95% speed of nominal speed | < 10 min | |
| Purge / vent port | G 1/4" | |
| Cooling water connection | G 3/8" | |
| Weight | 40 kg (88 lbs) | |
| Supply voltage | 100 - 240 V | |
| Max. power consumption | 700 VA | |
Specification
| Type | Label | Description | Download |
|---|---|---|---|
|
Leybold TURBOVAC T 1600 - REBUILT | Operating Instructions | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Leybold Vacuum TURBOVAC T 1600 Turbomolecular Pump - REBUILT 800040V1144 - DN 200 ISO-F 800040V2144 - DN 200 ISO-F Profibus 800040V1444 - DN 250 ISO-F 800040V2444 - DN 250 ISO-F Profibus 800040V1544 - DN 250 ISO-F 800040V1844 - DN 250 CF 800040V2844 - DN 250 CF Profibus
