Pfeiffer ACP 90 - NEW
Call for Price
| Weight | 165 lbs |
|---|---|
| Pumping Speed | 88 m3/h |
| Ultimate Pressure | 1.6 x 10-1 mbar |
Pfeiffer ACP 90 Multi-Stage Semiconductor Dry Roots Vacuum Pump - NEW
ACP multi-stage roots vacuum pumps are renowned for their high reliability, cleanliness and robustness.
With their contact-free operation and multi-stage compression, they generate vacuum that is free of oil and particles. An integrated air cooling system ensures consistent performance and durability.
Available in various versions, the ACP series is the ideal choice for applications requiring clean and dry vacuum across different industries, such as semiconductor manufacturing, vacuum packaging, medical and pharmaceutical, R&D or analytics.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Max. pumping speed | 88 m3/h |
| Ultimate pressure w/out dillution | 3 x 10-2 mbar |
| Ultimate pressure w/ gas-ballast valve | 1.6 x 10-1 mbar |
| Max. continuous inlet pressure | 1,013 mbar |
| Max. water pumping capacity | 2,400* g/h |
| Power consumption at ultimate pressure | 1.3 kW |
| Max. power consumption | 2 kW |
| Supply voltage 1-phase / Supply voltage 2-phase | 200-240 VAC |
| Supply voltage 3-phase | 380-480 VAC |
| Sound pressure level at ultimate pressure | < 65 dB(A) |
| Cooling method | Air |
| Max. leak rate | < 5 x 10-6 hPa·l/s |
| Connecting flange (in) | DN 40 ISO-KF |
| Connecting flange (out) | DN 40 ISO-KF |
| Dimensions (L x W x H) | 671 x 319 x 324 mm |
| Weight | 75 kg |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer ACP 90 Multi-Stage Semiconductor Dry Roots Vacuum Pump - NEW
-
