Alcatel 2012A - REBUILT
Call for Price
In stock
SKU
REBUILT_2012
| Weight | 216 lbs |
|---|---|
| Pumping Speed | 42.4 cfm |
| Ultimate Pressure | 3 x 10-4 mbar |
Pfeiffer Adixen Alcatel 2012A Instrument Pascal Rotary Vane Vacuum Pump - REBUILT
Rebuilt with one year warranty. Pfeiffer Adixen Alcatel 2012 Instrument (analytical series) Pascal rotary vane vacuum pumps. These have dual voltage: 115-230V motors and have a manual gas ballast. Fill out our request for quote form.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Specifications | Unit | 1004A | 2004A | 2008A | 1012A | 2012A | 2020A | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Frequency | Hz | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Number of stages | 1 | 2 | 2 | 1 | 2 | 2 | |||||||
| Nominal rotational speed | rpm | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 |
| Free air displacement | m3/h (cfm) | 4.5 | 5.4 (3.2) | 4.5 | 5.4 (3.2) | 10 | 12 (7) | 15 | 18 (11) | 15.7 | 18 (11) | 22.4 | 26.9 (15.9) |
| Air displacement Pneurop method | m3/h | 3.7 | 4.5 | 4 | 4.8 | 7.5 | 9 | 11 | 13 | 12 | 15 | 18 | 21.6 |
| Partial pressure w/out gas ballast | mbar | < 5 x 10-2 | < 1 x 10-4 | < 2 x 10-2 | < 1 x 10-4 | ||||||||
| Oil capacity | liters | 1.12 | 0.75 | 1 | 1.16 | 0.8 | |||||||
| Weight (three-phase) | kg | 15.5 | 18 | 19 | 19.5 | 20 | 26.7 | ||||||
| Weight (single-phase) | kg | 22 | 24.5 | 25.5 | 25 | 25.5 | 28.3 | ||||||
| Inlet & exhaust Pneurop flange | NW 25 | ||||||||||||
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Adixen Alcatel 2012A Instrument Pascal Rotary Vane Vacuum Pump - REBUILT
