Pfeiffer Adixen Alcatel 2021C2 - REBUILT
Call for Price
In stock
SKU
REBUILT_2021C2
| Weight | 62 lbs |
|---|---|
| Pumping Speed | 14.6 cfm |
| Ultimate Pressure | 2.25 x 10-3 torr |
Pfeiffer Adixen Alcatel 2021C2 Pascal Rotary Vane Vacuum Pump - REBUILT
Rebuilt with one year warranty. Pfeiffer Adixen Alcatel 2021C2 Pascal rotary vane vacuum pumps. These have dual voltage: 115-230V motors and have a manual gas ballast. Fill out our request for quote form.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Specifications | Unit | 2010C2 | 2015C2 | 2021C2 | |||
|---|---|---|---|---|---|---|---|
| Frequency | Hz | 50 | 60 | 50 | 60 | 50 | 60 |
| Number of stages | 2 | ||||||
| Rotation speed | rpm | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 |
| Nominal pumping speed | m3/h (cfm) | 9.7 | 11.6 (6.8) | 15 | 18 (10.6) | 20.7 | 24.8 (14.6) |
| Pneurop pumping speed | m3/h (cfm) | 8.5 | 10.2 (6) | 12.5 | 15 (8.8) | 16.5 | 20 (11.8) |
| Max. pumping speed | m3/h | 9.7 | 11.6 | 15 | 18 | 20.7 | 24.8 |
| Max. gas throughput | mbar l/s | 2,722 | 3,263 | 4,222 | 5,063 | 5,833 | 6,977 |
| Emission sound pressure level without gas ballast | dB(A) | < 52 | < 54 | < 53 | < 54 | < 53 | < 55 |
| Partial ultimate pressure | Torr / mbar / Pa | 3.75 x 10-4 / 5 x 10-4 / 5 x 10-2 | |||||
| Ultimate pressure with gas ballast closed | Torr / mbar / Pa | 2.25 x 10-3 / 3 x 10-3 / 3 x 10-1 | |||||
| Max. pressure at inlet in continuous operation | Torr / mbar / Pa | < 8 / 10 / 1 x 10-3 w/out oil recovery < 75 / 100 / 1 x 10-4 w/ oil recovery |
|||||
| Oil capacity | liters | 0.95 | 0.98 | ||||
| Weight (pump + motor) | kg (lbs) | 26 (57) | 27 (59.5) | 28 (62) | |||
| Inlet and outlet, Pneurop nipples | DN 25 ISO-KF | ||||||
| Type | Label | Description | Download |
|---|---|---|---|
|
Pfeiffer Adixen Pascal Series - REBUILT | Operating Instructions | Download |
|
|
Alcatel Pascal Series - REBUILT | User's Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Adixen Alcatel 2021C2 Pascal Rotary Vane Vacuum Pump - REBUILT
