Pfeiffer Adixen Alcatel 2021i - REBUILT
Call for Price
| Weight | 62 lbs |
|---|---|
| Pumping Speed | 14.6 cfm |
| Ultimate Pressure | 2.25 x 10-3 torr |
Pfeiffer Adixen Alcatel 2021i Instrument Pascal Rotary Vane Vacuum Pump - REBUILT
Rebuilt with one year warranty. Pfeiffer Adixen Alcatel 2021i Instrument (analytical series) Pascal rotary vane vacuum pumps. These have dual voltage: 115-230V motors and the optional internal oil pump. This pump is necessary when the ballast is used for extended periods but is not advisable for pumps running with particulate in the oil. We have added have the standard manual ballast since we received them with automatic ballasts. Fill out our request for quote form for other concerns.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Specifications SD, I, C1 | Unit | 1005SD | 1015SD | 2005 | 2010 | 2015 | 2021 | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Frequency | Hz | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 | 50 | 60 |
| Number of stages | 1 | 2 | |||||||||||
| Rotation speed | rpm | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 | 1,500 | 1,800 |
| Nominal pumping speed | m3/h (cfm) | 5.4 | 6.5 (3.8) | 15 | 18 (10.6) | 5.4 | 6.5 (3.8) | 9.7 | 11.6 (6.8) | 15 | 18 (10.6) | 20.7 | 24.8 (14.6) |
| Pneurop pumping speed | m3/h (cfm) | 4.8 | 5.5 (3.2) | 12.5 | 15 (8.8) | 4.8 | 5.7 (3.4) | 8.5 | 10.2 (6) | 12.5 | 15 (8.8) | 16.5 | 20 (11.8) |
| Max. pumping speed | m3/h | 4.5 | 5.5 | 13.5 | 16 | 4.8 | 5.5 | 9.7 | 11.6 | 15 | 18 | 20.7 | 24.8 |
| Max. gas throughput | mbar l/s | 1,256 | 1,547 | 3,805 | 4,500 | 1,350 | 1,547 | 2,722 | 3,263 | 4,222 | 5,063 | 5,833 | 6,977 |
| Partial ultimate pressure | Torr / mbar / Pa | - | 7.5 x 10-5 / 1 x 10-4 / 1 x 10-2 | ||||||||||
| Ultimate pressure with gas ballast closed | Torr / mbar / Pa | 3.75 x 10-2 / 5 x 10-2 / 5 | 1.5 x 10-3 / 2 x 10-3 / 2 x 10-1 | ||||||||||
| Ultimate pressure with gas ballast open | Torr / mbar / Pa | 3 / 4 / 4 x 102 | 5.25 / 7 / 7 x 102 | 7.5 x 10-3 / 1 x 10-2 / 1 | |||||||||
| Max. pressure at inlet in continuous operation | Torr / mbar / Pa | < 75 / 100 / 1 x 104 w/out oil recovery < 760 / 1,013 / 10.13 x 104 w/ oil recovery |
< 8 / 10 / 1 x 10-3 w/out oil recovery < 75 / 100 / 1 x 10-4 w/ oil recovery |
||||||||||
| Maximum exhaust relative overpressure | bar | 0.50 | |||||||||||
| Oil capacity | liters | 1.1 | 1.0 | 0.83 | 0.95 | 0.98 | |||||||
| Maximum water vapour pumping capacity | mbar (Pa) | 30 (3 x 103) | 25 (25 x 102) | 35 (35 x 102) | 30 (3 x 103) | 35 (35 x 102) | 25 (25 x 102) | 20 (20 x 102) | 15 (15 x 102) | 12 (12 x 102) | 10 (1 x 103) | 7 (7 x 102) | |
| Water vapour pumping capacity | g/h | 120 | 130 | 330 | 370 | 120 | 110 | 125 | 100 | 110 | 100 | 90 | |
| Emission sound pressure level without gas ballast | dB(A) | < 52 | < 54 | < 56 | < 55 | < 56 | < 55 | < 56 | |||||
| Weight (pump + motor) | kg (lbs) | 21 (46) | 24.5 (54) | 25 (55) | 26 (57) | 27 (59.5) | 28 (62) | ||||||
| Inlet and outlet end fittings | DN 25 ISO-KF | ||||||||||||
| Type | Label | Description | Download |
|---|---|---|---|
|
Pfeiffer Adixen Pascal Series - REBUILT | Operating Instructions | Download |
|
|
Alcatel Pascal Series - REBUILT | User's Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Adixen Alcatel 2021i Instrument Pascal Rotary Vane Vacuum Pump - REBUILT AM697767 1-phase hydrocarbon 100-240V # 221AGALZS AM697767 1-phase hydrocarbon 115V # 221AGALZS AM716895 1-phase hydrocarbon 100-230V # 221AHALZS
