Pfeiffer DUO 2.5 - REBUILT
Call for Price
In stock
SKU
REBUILT_DUO2.5
| Weight | 24 lbs |
|---|---|
| Pumping Speed | 2.5 m3/h |
| Ultimate Pressure | ≤ 6 x 10-3 mbar |
Pfeiffer Vacuum DUO 2.5 Rotary Vane Pump - REBUILT
Vacuum pump of UNO/DUO series are oil-sealed, single/two stage rotary van vacuum pumps. The vacuum pumps are equipped with a high vacuum safety valve that vacuum seals the vacuum chamber and vents the pump at the same time when the pump is at standstill.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Emission sound pressure level without gas ballast | ≤ 53 dB (A) |
| Flange (in) | DN 16 ISO-KF |
| Flange (out) | Hose Fitting |
| Leak rate safety valve | 1 x 10-4 mbar l/s |
| Mains requirement: voltage (range) | 220-240 V (± 10 %) 50/60 Hz |
| Operating fluid | P3 |
| Operating fluid filling | 0.4 l |
| Pumping speed at 50 Hz | 2.5 m3/h |
| Pumping speed at 60 Hz | 2.9 m3/h |
| Rated power 50 Hz | 0.15 kW |
| Rated power 60 Hz | 0.18 kW |
| Rotation speed at 50 Hz | 3,000 rpm |
| Rotation speed at 60 Hz | 3,600 rpm |
| Switch | Yes, with 2 m mains cable without plug |
| Ultimate pressure with gas ballast | ≤ 6 x 10-3 mbar |
| Ultimate pressure without gas ballast | ≤ 6 x 10-3 mbar |
| Weight | 10.5 kg / 24 lbs |
| Type | Label | Description | Download |
|---|---|---|---|
|
Pfeiffer UNO/DUO 2.5 - REBUILT | Operating Instructions | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Vacuum DUO 2.5 Rotary Vane Pump - REBUILT PKD41055D / PK D41 055 D
