Pfeiffer DUO 3 - REBUILT
Weight
25 lbs
Pumping Speed
2.5 m3 /h
Ultimate Pressure
3 x 10-3 mbar
Pfeiffer Vacuum DUO 3 Rotary Vane Pump - REBUILT
Vacuum pump of UNO/DUO series are oil-sealed, single/two stage rotary van vacuum pumps. The vacuum pumps are equipped with a high vacuum safety valve that vacuum seals the vacuum chamber and vents the pump at the same time when the pump is at standstill.
Questions? send an email to our sales team!
Flange in/out
DN 16 ISO-KF
Pumping speed at 50 Hz
2.5 m3 /h
Pumping speed at 60 Hz
2.9 m3 /h
Ultimate pressure w/ gas ballast
3 x 10-3 hPa
Ultimate pressure w/out gas ballast
Exhaust pressure min.
Atmospheric pressure
Exhaust pressure max.
1,500 hPa
Rotation speed at 50 Hz
3,000 min-1
Rotation speed at 60 Hz
3,600 min-1
Leak rate safety valve
≤ 1 x 10-5 Pa m3 /s
Emission sound pressure level w/out gas ballast at 50 Hz
≤ 53 dB(A)
Ambient temperature
12 - 40°C
Protection category
IP 40
Rated power at 50 Hz
0.15 kW
Rated power at 60 Hz
0.18 kW
Switch
Yes
Mains cable
No
Shipping & storage temperature
-25 to +55°C
Operating fluid filling
0.4 l
Weight
11.3 kg / 25 lbs
Cooling method, standard
Air
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Vacuum DUO 3 Rotary Vane Pump - REBUILT
PKD57504A / PK D57 504 A
PKD57711A / PK D57 711 A
