Pfeiffer TPH 110 - REBUILT
Call for Price
| Weight | 25 lbs |
|---|---|
| Pumping Speed | 33-38 l/s |
| Ultimate Pressure | 1 x 10-10 mbar |
Pfeiffer Balzers TPH 110 Turbomolecular Vacuum Pump - REBUILT
TPH and TPU models of the Pfeiffer Balzers turbo are identical with regard to their design, the only difference being the intake flange. The TPH pumps have a KF or ISO-K flange, while the TPU pumps have a CF flange. The same letter signification applies to TMU and TMH pumps.
The Pfeiffer Balzers 330, 510 and 2200 are available with the flange being fitted on top or bottom as standard. Both models may also be equipped with a lateral flange by rearranging the pump's support legs. The TPH 330 comes with a six month warranty. We also offer repair services.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Type | Label | Description | Download |
|---|---|---|---|
|
Balzers Pfeiffer TPH/TPU 110 - REBUILT | Operating Instructions | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Balzers TPH 110 Turbomolecular Vacuum Pump - REBUILT PMP01109 / PM P01 109 TPH 110
