Pfeiffer TPH 1501 - REBUILT

Call for Price

In stock
SKU
REBUILT_TPH1501
Weight 107.8 lbs
Pumping Speed 1,450 l/s
Ultimate Pressure 10-7 h Pa

Pfeiffer Vacuum TPH 1501 Turbomolecular Pump - REBUILT

With one year warranty; special volume pricing. Pfeiffer Vacuum TPH 1501 turbo pump. We offer repair service and are capable of rebuilding, balancing and testing this pump. Contact us for flange and rotation options.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Inlet connection DN 250 ISO-K
Outlet connection DN 40 ISO-KF
Pumping Speed (N2) 1,450 l/s
Ultimate Pressure < 10-7 hPa
Compression ratio (N2) >108
Cooling method Water
RUN-up time 5 Min
Venting connection G 1/8"
Weight 49kg (107.8lbs)

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

Pfeiffer Vacuum Turbomolecular Pump - REBUILT

TPH 1501     PMP03775 / PM P03 775  DN 250 ISO-K
TPH 1501 U P PMP03610 / PM P03 610  DN 250 ISO-K
