Pfeiffer TSH 071 - REBUILT
Call for Price
In stock
SKU
REBUILT_TSH071
| Weight | 100 lbs |
|---|---|
| Pumping Speed | 33-60 l/s |
| Ultimate Pressure | 1 x 10-7 mbar |
Pfeiffer Vacuum TSH 071 Turbomolecular Pump System
The plug and play type TurboCubeTM pumping stations are fully automatically operating pumping units. If the turbo pump is supplied separately, the venting valve and the cooling unit must be connected to the pump, then the pump is to be connected to the pumping station.
The integrated display and operating unit DCU 001 serves to control and monitor the pumping station and works in conjunction with the electronic drive unit TC 600.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Specifications | DN 40 ISO-K | DN 63 ISO-K |
|---|---|---|
| Pumping speed (N2) | 33 l/s | 60 l/s |
| Final pressure w/ | ||
| Rotary vane pumps | < 1 x 10-7 mbar | |
| Diaphragm pumps | < 1 x 10-7 mbar | |
| Pumping speed, backing pump mains frequency at 50 Hz | ||
| MVP 015-2 | 0.9 m3/h | |
| MVP 035-2 | 2.1 m3/h | |
| MVP 055-3 | 3.3 m3/h | |
| DUO 2.5 | 2.5 m3/h | |
| UNO 5 | 5 m3/h | |
| DUO 5 | 5 m3/h | |
| DUO 10 | 10 m3/h | |
| Mains connection - power consumption w/ | ||
| MVP 015-2 | 140 VA | |
| MVP 035-2 | 280 VA | |
| MVP 055-3 | 300 VA | |
| DUO 2.5 | 230 VA | |
| UNO 5 | 230 VA | |
| DUO 5 | 470 VA | |
| DUO 10 | 650 VA | |
| Weight w/ | ||
| MVP 015-2 | 28 kg | |
| MVP 035-2 | 32 kg | |
| MVP 055-3 | 37 kg | |
| DUO 2.5 | 32 kg | |
| UNO 5 | 32 kg | |
| DUO 5 | 44 kg | |
Specifications
| Type | Label | Description | Download |
|---|---|---|---|
|
Pfeiffer TMH/TMU 071 - REBUILT | Operating Instructions | Download |
|
|
Pfeiffer TSH/TSU 071 - 521 - REBUILT | Operating Instructions | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Pfeiffer Vacuum TSH TSU 071 Turbomolecular Pump System
