Call for Price

In stock

VIC Vacuum Instruments Corporation, LLC MD-490S Portable Dry Helium Leak Detector Sniffer - NEW

The dedicated tracer gas sniffing only portable MD-490S is considered the Leak Detection “Work Horse” by manufacturing companies worldwide.

The MD-490S is the highest sensitivity sniffer with a response time less than 0.5 seconds and the ability to zero-out background, this is the most aggressive portable leak detector in the industry, with advanced features designed specifically for industrial use.

  • Vibra-Leak Probe with background suppression button provides tactile feedback when leak rate exceeds the reject set point; Ideally suited for noisy environments where audio alarms cannot be heard or where leak detectors are in close proximity; Vibra-Leak Probe solves background tracer gas problems during the test.
  • Tracer Gas Background Suppression with a push of a button, the MD-490S eliminates the tracer gas background.
  • Most Sensitive Sniffer Available with 10-8 sensing capabilities through enhanced tracer gas collector design and signal processing
  • Fully Interactive System Diagnostics include critical parameters such as run times, operating voltages / currents and pressures.
  • Graphical and Numerical Displays of leak rate values.
  • Sealed Membrane Keypad for long life in harsh environments.
  • Fully Automatic Calibration sequence with built-in NIST calibrated gas leak which prompts the operator to insert probe into the built-in leak and adjusts the machine’s leak rate reading to match the leak value.
  • Dry (oil-free) Vacuum Pumping minimizes maintenance and potential oil contamination problems.
  • Probe Blockage Alarm ensures proper system performance.
  • Front Panel Key Lock-Out prevents unauthorized use.
  • High Output Adjustable Audio Alarm up to 110 dB.

Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!

Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.

VIC Vacuum Instruments Corporation, LLC MD-490S Portable Dry Helium Leak Detector Sniffer - NEW

966490 / 966-490  MD-490S  Portable Dry Helium Sniffing Leak Detector which can be fully integrated with our Smart Charge III Evacuation and Backfill Station
966495 / 966-495  MD-490S DG  Dual Gas Portable Helium / Hydrogen Sniffing Leak Detector
966493 / 966-493  MD-490M  Helium Leak Detector
966494 / 966-494  MD-490MV  Vacuum Chamber Test System / System for Vacuum Process Leak Testing
