CTI-Cryogenics 9650 - REBUILT
Call for Price
In stock
SKU
REBUILT_9650
| Weight | 260 lbs |
|---|---|
| Power | 5.5 kW |
Brooks CTI-Cryogenics 9650 Helium Compressor - REBUILT
Atlas Copco purchased CTI from Brooks and placed it under the Edwards brand.
- Call for pricing and availability on the Brooks CTI-Cryogenics 9650 compressor, shipped with a one year parts and labor warranty.
- 9650 is three-phase and either low or high voltage (LV/HV) (230 or 460V).
- New helium lines and accessories are available.
- We also offer repair service. View the other compressor models.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Low Voltage | |
|---|---|
| Cooling | Water |
| Capacity (pump model) | 1 On-Board (10, 400, 500) or 3 On-Board (100, 7, 8, 8F) |
| Operating voltage range | 180 - 253 VAC |
| Line frequency | 50/60 Hz |
| Phase | 3 |
| Nominal input power | 5.5 kW |
| Nominal power factor | 0.85 |
| Rated full load / locked rotor current | 16.2 / 80 |
| Minimum electrical service | 30 Amps |
| Maximum inlet temperature | 90°F (32°C) |
| Minimum inlet temperature | 50°F (10°C) |
| Flow rate | 2.75 ± 1.25 gpm (10.4 ± 4.7 lpm) |
| Maximum inlet pressure | 100 psi (6.9 bars) |
| Alkalinity | 6.0 - 8.0 pH |
| Calcium carbonate | < 75 ppm |
| Input power cable (Customer supplied) |
600 VAC 10 / 12 Gauge (LV / HV), 3 conductor wire with ground Must conform to local electrical codes |
| Ambient operating temperature range | 50 - 100ºF (10 - 38ºC) |
| Interface | Cryopump power receptacles: mates with the CTI-CRYOGENICS supplied cryopump power cable for single pump use. Mates with remote junction box power cable for multiple cryopump use. |
| Gas supply connector | 1/2 in. Aeroquip self-sealing coupling, male thread. |
| Gas return connector | 1/2 in. Aeroquip self-sealing coupling, female thread. |
| Remote control receptacle | 24VAC, 2.7A inductive mates with P5 connector Type MS3106A |
| Adsorber service schedule | 3 Years |
| Weight | 260 lbs / 118 kg |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Brooks CTI-Cryogenics 9650 Helium Compressor - REBUILT P/N 8135911G001 low voltage 200-230 VAC 50/60 Hz 3-phase
