Edwards EDP250 - NEW
Call for Price
In stock
SKU
NEW_EDP250
| Weight | 1,667 lbs |
|---|---|
| Pumping Speed | 260 m3/h |
| Ultimate Pressure | 5 x 10-1 mbar |
Edwards EDP250 Chemical Dry Vacuum Pump - NEW
The Edwards EDP pumps are based on Edwards’ oil-free, non-contacting, award-winning, reverse claw mechanism. They provide consistent vacuum at high efficiencies and low costs of ownership. Dry pumps completely eliminate all problems of process contamination and creation of polluted effluent, which are experienced with traditional wet vacuum pump technologies.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Maximum pumping speed | |
| 50 Hz | 260 m3h-1 / 153 ft3min-1 |
| 60 Hz | 320 m3h-1 / 188 ft3min-1 |
| Capacity at 10 mbar (7.5 Torr) | |
| 50 Hz | 255 m3h-1 / 150 ft3min-1 |
| 50 Hz | 315 m3h-1 / 185 ft3min-1 |
| Ultimate vacuum | |
| 50 Hz | 0.5 mbar / 0.4 Torr |
| 60 Hz | 0.2 mbar / 0.2 Torr |
| Maximum back pressure | |
| Standard | 1150 mbar / 2.2 psig |
| Optional* | 1300 mbar / 4.4 psig |
| Power consumption at 10 mbar (7.5 Torr) | |
| 50 Hz | 6.0 kW / 8.0 hp |
| 60 Hz | 6.0 kW / 8.0 hp |
| Standard motor (380 – 400 V, 3 ph, 50 Hz) | |
| 50 Hz | 11 kW |
| 60 Hz | 15 kW |
| Standard motor (200 – 460 V, 3 ph, 60 Hz) | |
| 50 Hz | 15 hp |
| 60 Hz | 20 hp |
| Cooling water flow rate (adjustable) | |
| 50 Hz | 1 – 10 l min-1 / 0.3 – 2.6 gal min-1 |
| 60 Hz | 1 – 10 l min-1 / 0.3 – 2.6 gal min-1 |
| Cooling water supply pressure | 2 – 10 barg / 29 – 145 psig |
| Seal purge flow (maximum), regulated to 0.3 - 0.5 barg (5 – 7 psig) |
20 l min-1 / 0.7 ft3min-1 |
| Seal purge supply pressure (minimum - maximum) |
2 – 10 barg / 29 – 145 psig |
| Noise (max. with exhaust silencer) | |
| 50 Hz | 78 dB(A) |
| 60 Hz | 79 dB(A) |
| Weight (with frame and standard motor) | |
| 50 Hz | 756 kg / 1667 lbs |
| 60 Hz | 848 kg / 1870 lbs |
| Inlet | 3’’ ANSI / DN80 |
| Outlet | 2’’ ANSI / DN50 |
| Pumping mechanism | 3 stage reversed claw |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards EDP Drystar Series - NEW | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards EDP250 Chemical Dry Vacuum Pump - NEW A70543000 EDP250 50/60Hz Bareshaft
