Edwards Stokes 306 - REBUILT
Weight
200 lbs
Motor Power
5 hp
Edwards Stokes 306 Roots Vacuum Blower - REBUILT
The Stokes 3" Series mechanical booster pumps provide high throughput pumps for industrial and arduous chemical applications. Utilizing reliable, rugged designs, these pumps offer a low cost, space saving pumping system.
Questions? send an email to our sales team!
Stokes 306
Direct Drive
V-Belt Drive
Displacement
245 cfm / 416 m3 hr
Motor speed
60 Hz: 3,600 rpm
Inlet / outlet flanges
3" ASA
Oil capacity
1.75 pints / 0.83 liters
Max. pressure differential
380 Torr
Max. temperature rise
275°F / 135°C
Max. discharge temperature
375°F / 191°C
Drive hp
5 hp Max
Weight
200 lb / 91 kg
150 lb / 68 kg
Specifications
Type
Label
Description
Download
BOC Edwards Stokes 306 & 310 - REBUILT
User's Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards Stokes 306 Roots Vacuum Blower - REBUILT
900-306-1 306-1 / 306-001 Vertical flow V-belt drive
900-306-2 306-2 / 306-002 Horizontal flow V-belt drive foot mounting
900-306-3 306-3 / 306-003 Horizontal flow V-belt drive
900-306-401 306-401 306-41 Vertical flow direct drive
900-306-402 306-402 306-42 Horizontal flow direct drive foot mounting
900-306-403 306-403 Vertical flow direct drive
900-306-404 306-404 Horizontal flow direct drive foot mounting
900-306-405 306-405 Vertical flow direct drive
900-306-042 306-042H HV oxygen service
