Edwards Stokes 900-607 - REBUILT
Weight
760 lbs
Motor Power
10 hp
Edwards Stokes 900-607 Roots Vacuum Blower - REBUILT
The Stokes 6" Series mechanical booster pumps provide high throughput pumps for industrial and arduous chemical applications. Utilizing reliable, rugged designs, these pumps offer a low cost, space saving pumping system.
Questions? send an email to our sales team!
Specifications
Horizontal flow
Vertical flow
Displacement
V belt (2,750 rpm)
1,589 m3 h-1 / 935 ft3 min-1
Direct drive (3,000 rpm)
1,733 m3 h-1 / 1,020 ft3 min-1
Direct drive (3,600 rpm)
2,080 m3 h-1 / 1,224 ft3 min-1
Inlet / outlet flanges
6” ASA / ANSI
Motor power EU / Asia
7.5 kW
Motor power US TEFC
10 hp
Cooling water
7.6 - 11.4 l min-1 / 2 - 3 gal min-1
Oil capacity
1.9 liter / 0.51 gal
4.1 liter / 1.1 gal
Max pressure differential
506 mbar / 380 Torr
Max temp rise
135°C / 275°F
Max discharge temp
191°C / 375°F
Weight bare shaft
215 kg / 475 lbs
Weight TEFC direct drive
345 kg / 760 lbs
Recommended oil
V-Lube H
Type
Label
Description
Download
Edwards MHR & MVR 607 - 622 - REBUILT
Instruction Manual
Download
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards Stokes 900-607 Roots Vacuum Blower - REBUILT
900607MVR101 / 900-607-VAPS 460V 3-phase 60Hz
