Edwards XDS46i - NEW
| Weight | 105 lbs |
|---|---|
| Motor Power | 0.7 hp |
| Pumping Speed | 60 m3h-1 |
| Ultimate Pressure | 4 x 10-2 torr |
Edwards XDS46i Dry Scroll Vacuum Pump - NEW
The XDS46i pump is a development on the XDS35i and thus shares many of the same features and benefits but with a peak speed boosted to 40m3/hr. The XDS46i is optimised for maximum pumping speed at inlet pressures between 1 mbar and 10 mbar making it ideally suited for LCMS and ICPMS applications requiring a higher pumping speed than that offered by the XDS35i. Recent improvements in tip seal technology have lead to reduced tip seal wear therefore giving a longer time between service interventions. The inverter drive controls the motor characteristics and ensures the pump always runs at optimum speed and allows the user to control the pump remotely.
Questions? Please call our toll free number at 866-332-0500 or send an email to our sales team!
| Displacement 50 or 60 Hz | 60 m3h-1 / 35 ft3min-1 |
| Peak pumping speed 50 or 60 Hz | 40 m3h-1 / 23.5 ft3min-1 |
| Ultimate vacuum (Total pressure) | 5 x 10-2 mbar / 4 x 10-2 Torr |
| Max continuous inlet pressure | 40 mbar / 30 Torr |
| Max continuous outlet pressure | 0.2 bar gauge / 2.9 psig* |
| Max allowed inlet and GB pressure | 0.5 bar gauge / 7 psig |
| Motor power | 0.52kW |
| Power connector | IEC EN60320 C19 |
| Nominal rotation speed | 1,750 rpm |
| Weight | 48 kg / 105 lb |
| Inlet flange | NW40 |
| Exhaust flange | NW25 |
| Noise level | 55.4 dB(A) |
| Vibration | < 4.5 mms-1 (rms) |
| Leak tightness (static) | < 1 x 10-6 mbar l/s |
| Operating temperature range | 10 to 40°C / 50 to 104°F |
| Type | Label | Description | Download |
|---|---|---|---|
|
Edwards XDS46i - REBUILT | Instruction Manual | Download |
Need modifications to this item? PTB Sales' expert team of engineers can configure products to your specific needs.
Edwards MODEL XDS46i Dry Scroll Vacuum Pump - NEW CODE No. A731-01-983 / A73101983 XDS46i 100-120V 200-230V 50/60Hz set to 230V single-phase CODE No. A731-06-983 / A73106983 XDS46iC 100-120V 200-230V 50/60Hz set to 230V 1-phase
